Communication - LEGRAND IME CONTO D6-Pd Installation

Energy meter 100A
direct connection

9. COMMUNICATION

RS485 Modbus wiring diagram:
IF4E011/SXIIP
ETHERNET
RJ45
Required use of Belden
RS485:
(1)
for a maximum length 50 m
Resistance not furnished supplied to be connected between "+ and -" of the 1
(2)
Ethernet: Cat. 6 (FTP/UTP)
(3)
Modbus communication tables
- MODBUS communication tables are available at http://www.imeitaly.com, inserting the "CE6DJ0DTCL1" code in the search field.
Technical data sheet: IDP000207EN_01
RS-485
(2)
+ – SG
(3)
9842, Belden 3106A (or equivalent) for a maximum length of 1000 m, or Category 6 cable (FTP or UTP)
Tomek GmbH - messtechnik@tomek.at - 01/61003-0
Codes: CE6DJ0DTCL1
Model: CONTO D6-Pd
CE6DJ0DTCL1
N°1
+ – SG
and last device of the line
st
Updated: -
CE6DJ0DTCL1
N°2
R
+ – SG
Created: 02/04/2019
CE6DJ0DTCL1
N°n
(2)
+ – SG
T
7 | 7
