Instructions for the installer
3.3

Fitting the front moulding

For some cooker models, a front moulding is available to complement its aesthetics.
Before turning the cooker over, we recommend removing all the parts that are not stably attached
to it, in particular the cooking hob grids and burners. To lighten the weight of the cooker, the
accessories inside the oven may also be removed, thereby preventing accidental damage during
the overturning operation.
3.3.1 70cm cooker with double oven and 100cm cooker with triple oven
The moulding is supplied as a standard fitting with the Sintesi and Genesi series.
To assemble, proceed as follows:
tilt the cooker backwards;
•
align the moulding A with the mounting position as shown in the illustration;
•
apply the moulding until it fits into the mounting position;
•
pull the moulding downward so that it hooks onto the 4 pins B (two on the back and one on
•
each side) present on the cooker.
3.3.2 Genesi series cooker
The moulding is supplied as a standard fitting with the Genesi series whereas it is available only on
request (optional) for the Sintesi series.
To assemble, proceed as follows:
tilt the cooker backwards;
•
align the moulding A with the mounting position as shown in the illustration;
•
apply the moulding until it fits into the mounting position;
•
pull the moulding downward so that it hooks onto the 4 pins B (two on each side) present on
•
the cooker.
91
