5. Description of controls

5.1
All the commands and controls for the cooking hob and oven are on the front panel.
The flame is lit by simultaneously pressing and turning the knob anticlockwise to
the low flame symbol .
To regulate the flow of the flame, turn the knob to between the maximum
minimum settings. Turn off the burner by returning the knob to position .
DESCRIPTION OF "MEGA WOK" BURNER KNOBS
The central "Mega Wok" burner is controlled by two
knobs: one switches on the inner central ring and the
second operates the outer ring on both the outside and
inside.
106

Instructions for the user

Front panel

DESCRIPTION OF HOB BURNER KNOB
LAYOUT OF BURNERS – Description of symbols
REAR LEFT
REAR CENTRE LEFT
CENTRE FRONT
FRONT CENTRE LEFT
FRONT LEFT
LAYOUT OF BURNER RINGS – Description of symbols
CENTRAL RING

THE CONTROL PANEL

and
REAR RIGHT
REAR CENTRE RIGHT
CENTRE REAR
FRONT CENTRE RIGHT
FRONT RIGHT
OUTER RING
