Clamping
Remove the locking device from the assembly head.
Move the assembly head into position as high and as far back as
possible and lock it again.
Now swivel the assembly tower backwards.
Wheel rims with asymmetric drop-centres should be positioned so
that the narrow bead seat is facing up.
Place the rim on the wheel lift with the narrow rim shoulder facing
outwards (1).
3
2
1
