1) Remove the filter from the filter basket. With a soft, dry brush, clean any accumulated debris
from the side screens of the filter and the filter basket (Fig. 18).
2) After repeated use, it may be necessary to wash the filter basket and filter. Hand wash in warm
water. After washing, set aside and allow to air dry for 24 hours.
IMPORTANT: Ensure the filter and filter basket are completely dry before reinstalling.
3) Insert the spare clean and dry filter into the basket and fit the basket into the dust bin ensuring
an air tight seal is formed around the dust bin opening.
4) Reconnect the dust bin to the handheld vacuum cleaner. To do so, position the locking tab on
the handheld unit within the locking grove located on the bottom of the dust bin. Press the other
end of the dust bin into position until you hear a 'click' (Fig. 19).
3. Cleaning the Motorised Floor Head and Removing Blockages
The motorised floor head may accumulate debris such as strings, hair and fibers. This type of
debris can wrap around the brush and diminish its ability to clean effectively.
The Easy-Cut blade in the motorised floor head will cut most debris accumulation away from the
brush roll. After every use, clean the brush roll with the Easy-Cut system by stepping on the button
for 1-2 seconds as illustrated while the vacuum cleaner is operating. Repeat above step more than
5 times for better performance (Fig. 20).
NOTE: It is recommended to use the Easy-Cut system while the battery is fully charged.
Remove Brush Roll for Manual Cleaning
WARNING!
extremely sharp edge inside. Do not touch the blade when performing maintenance.
1) Make sure the vacuum cleaner is turned OFF. Remove the floor head from the handle assembly
and turn it over to access the brush roll.
2) Unlock the brush roll tab using a flat head screwdriver or similar tool (Fig. 21).
3) Lift the brush roll out of the housing. Clean off debris and anything wrapped around the brush
(Fig. 22).
4) Align the brush roll to the drive side first, then insert the other end correctly. Ensure it is fully
and securely placed onto the mounting bracket. Lock the brush roll into place by securing the
locking tab back into position (Fig. 23).
Remove Motorised Floor Head Blockages
1) To clean out the motorised floor head, press the two release buttons, and pull the head away
from the handle assembly (Fig. 24).
2) Flex the connection hose to ensure you can see straight through the other end. If you can see
any blockages in this area, carefully remove them.
3) Reattach the motorised floor head onto the vacuum body (Fig. 25).
NOTE: Do not use scissors or other sharp objects to remove a blockage from the hose as these
may damage the hose.
The motorised floor head contains an EASY-CUT blade. It has an
