ADJUSTING THE FRICTION

IMPORTANT NOTES:

- The friction on the TCA Quadrant Add-On Airbus Edition modules is set to 50% by
default.
- In order to allow for precise adjustment accordi n g to your preferences, y ou c an use a
screwdriver with the correspondi n g head shape (not incl u ded) — or the crossbar included
with the TCA Quadrant Airbus Edition — to turn the friction adjustment screws.
1. Push both TCA Quadrant Add-On Airbus Edition module levers forward to their maximum
values, and then access the friction adjustment screw at the back of each module.
2. To increase the friction, turn the friction adjustment screw clockwi s e.
3. To decrease the friction, turn the fricti o n adjustment screw counterclockwise.
- To avoid damaging the friction system, be careful not to over-tighten t he adjus tment
screws: stop turning the screws when you feel resistance.
- Never completely unscrew the adjustment screws, to avoid the screws falli n g inside the
body of either TCA Quadrant Add-On Airbus Edition module.
