3.0 UNPACKING AND ASSEMBLY
3.4 Place the observation head into the top of the attachment and tighten the lock-screw.
3.5 Insert the eyepieces into the eye tubes.
3.6 Insert polarizer and analyzer filters into their slots in the metallographic attachment.
3.7 Connect the power cable of the epillumination to the appropriate connector on the rear:
All manuals and user guides at all-guides.com
Page 6
Connector
for LED
epillumination
