DJI Smart Controller
The DJI Smart Controller is a remote controller built with DJI's long-range transmission
technology OCUSYNC
and provides a live HD view from the aircraft's camera. The Smart Controller comes
with a number of aircraft and gimbal controls as well as customizable buttons and has
1
a built-in 5.5-inch high-brightness screen with multiple functions such as Bluetooth and
GNSS. Connection to the Internet via Wi-Fi is also supported. The Smart Controller has a
maximum working time of 2.5 hours*. 2 3
4
5
1
2 3
4
5
10 13
10 13
11
1. Antennas
2. Back Button / Function Button
3. Sticks
15
4. RTH Button
5. Flight Pause Button
16
6. Flight Mode Switch
7. Status LED
8. Battery Level LEDs
9. 5D Button
10. Power Button
11. Confirm Button / Customizable Button C3
12. Touch Screen
13. USB-C Port
14. Microphone
15. Gimbal Dial
* The Smart Controller is able to reach its maximum transmission distance (FCC) in a wide-open area
with no electromagnetic Interference at an altitude of about 400 ft (120 m).
The maximum runtime is tested in a laboratory environment. This value is for reference only.
2.0, offering a maximum transmission range of 6.2 mi (10 km)
TM
7 7 8
10 10 10 10 10 10 10 10 10 10 10 10 10 10
9 9 9 9
6
10 12
7 7 8
10 10 10 10 10 10 10 10 10 10 10 10 10 10
9 9 9 9
6
14
10 12
14
17 18 19
11
15
16
11
16. Record Button
17. HDMI Port
18. MicroSD Card Slot
15
19. USB-A Port
20. Focus / Shutter Button
16 21. Aperture/Shutter Adjustment Dial
21
20
22. Air Vent
23. Sticks Storage Slot
24. Customizable Button C2
25. Speaker
26. Customizable Button C1
27. Air Intake
21
17 18 19
21
17 18 19
22
23
24 25 26
27
20
20
