OVERVIEW CONT'D
9. SD/Micro SD 3.0: Secure Digital v3.0 UHS-I (Ultra High Speed) SDR12
(12.5Mbyte/s)/SDR25(25Mbyte/s)/SDR50(50Mbyte/s)/DDR50(50Mbyte/s)/
SDR104(104Mbyte/s) with simultaneous operation
10. USB-A 2.0 Female x 2 (near SD card slot, maximum 500mA downstream
charging and 480Mbps data transmission
11. USB-A 3.0 Female x 2 (Near power switch, maximum 5Gbps data
transmission, 900mA downstream charging
12. USB-A 3.0 Female with maximum 7.5W (5V/1.5A) downstream charging,
5Gbps data transmission
13. USB-C female (near USB-A, connect Type-C device) supports maximum
5Gbps data transmission and 1.5A downstream charging
14. Combo Audio In/Out 3.5mm: Supports both microphone and headphone
48KHz and CTIA
15. Power Switch
16. LED Light
• Green: On
• Off: Off
