PRODUCT OVERVIEW
3
10
14
1. Type-C Female (on the bottom, connects to host) DP1.2 Alt mode, with
bandwidth max 21.6Gbps (5.4Gbps per lane)
2. USB-C Male to Male Cable. Insert angled side in bottom of this product and
other side to USB-C host
3. Anti-theft K-Lock
4. USB-C Female: Connect USB-C PD Power Adapter (near HDMI) supports
maximum 100W Charging with fast role swap of PD3.0. Supports Dynamic
Current Detection and Power Distribution. Note: 4-18W (4W for no-load mode
and 18W for full-load mode) power will be dynamically provided to support
the functions of this product.
5. HDMI Female: Supports max 4k/30Hz, 6/8/10/12 bit color depth output,
output pixel format RGB4:4:4/YCbCr4:4:4/YCbCr4:2:2, HDCP 1.4
6. DisplayPort Female: Supports max 4k/30Hz. Mac OS: Up to 3 displays
simultaneously under SST mode showing the same picture or video with
maximum 1080p@60Hz, Windows: Up to 3 mirrored displays in SST mode at
1080p@60Hz or up to 3 extended displays in MST mode
7. VGA Female (1920x1200/60Hz)
8. RJ45 10/100/1000 Ethernet
4
5
6
7
8
9
10
1
2
11
15
13
16
12
