G (Ground)
Notice: All the connectors marked G or GND are common.
i
Connect the ground side of the alarm input and/or alarm output to the G (Ground)
connector.
AO (Alarm Output)
The camera can activate external devices such as buzzers or lights. Connect the device to
the AO (Alarm Output) and G (Ground) connectors.

Connecting the Power

Connect power of 12VDC for the camera. Connect the positive (+) pole to the ' + ' position
and the negative (-) pole to the ' - ' position.
• Be careful not to reverse the polarity when you connect the power cable.
• You can also use a router featuring PoE (Power over Ethernet) to supply power to
the camera.
