C C o o n n f f i i g g u u r r i i n n g g t t h h e e S S e e c c u u r r e e C C o o n n n n e e c c t t
T T o o o o l l s s r r e e q q u u i i r r e e d d : :
• S S e e c c u u r r e e C C o o n n n n e e c c t t scanner (521200380700) (option) or S S e e c c u u r r e e C C o o n n n n e e c c t t compatible product
• Stryker service tool (521205080001) (option)
N N o o t t e e - - Stryker service tool required if you use the S S e e c c u u r r e e C C o o n n n n e e c c t t scanner.
C C A A U U T T I I O O N N - - Always match the dip-switches on SB1 and SB2 to the product configuration to avoid the risk of head wall
damage.
P P r r o o c c e e d d u u r r e e : :
• Using the S S e e c c u u r r e e C C o o n n n n e e c c t t scanner:
1. Using the Stryker service tool, select the supplied soft configuration and settings.
2. Select S S a a v v e e C C o o n n f f i i g g u u r r a a t t i i o o n n (A) (Figure 4).
• Using a P P r r o o C C u u i i t t y y ™ bed:
1. Apply the brakes.
N N o o t t e e - - See the Model 3009 P P r r o o C C u u i i t t y y Operations Manual for steps to apply the brakes.
2. Confirm the S S e e c c u u r r e e C C o o n n n n e e c c t t connection to P P r r o o C C u u i i t t y y .
N N o o t t e e - - The icon will appear on the P P r r o o C C u u i i t t y y home screen when S S e e c c u u r r e e C C o o n n n n e e c c t t has connected.
3. Enter the service menu and select C C o o n n f f i i g g u u r r a a t t i i o o n n (B) (Figure 5).
N N o o t t e e - - See the Model 3009 P P r r o o C C u u i i t t y y Maintenance Manual for steps to access the service menu.
EN 10
F F i i g g u u r r e e 4 4 – – S S t t r r y y k k e e r r s s e e r r v v i i c c e e t t o o o o l l
A
5212-009-205 Rev AA.1
