1 DUST COVER
2 LEFT SPEAKER
3 DIAL POINTER
4 3.5MM HEADPHONE JACK
5 POWER LED INDICATOR
6 POWER OFF/FUNCTION
SELECTOR BUTTON
7 BAND/FM STEREO SELECTOR
8 RIGHT SPEAKER
9 ROTARY VOLUME KNOB
10 TUNING KNOB
11 FM STEREO LED INDICATOR
12 SPINDLE ADAPTOR
13 33/45/78 RPM SPEED SELECTOR
14 PICK-UP HOLDER
15 LINE OUT SOCKET
16 FM ANTENNA
17 AUTO STOP SWITCH
18 AC CORD
CONTENT OF DELIVERY
➢ Main Unit
➢ Instruction manual

PRECAUTIONS FOR USE

➢ Unpack all parts and remove protective material.
➢ Do not connect the unit to the mains before checking the mains voltage and before all other
connections have been made.
➢ Do not cover any vents and make sure that there is a space of several centimeters around
the unit for ventilation.
TOP COVER ASSEMBLY
➢ Push the metal bracket to rear side.
➢ Connect the metal bracket to the top cover.
➢ Connect the hinge of the top cover to the main unit.

LOCATION OF CONTROLS

INSTALLATION
1
PL196H / English instruction manual
