FRAME
1 Unpack the pushchair frame from the
box and set the wheels asidee.
2 Unfold the pushchair by pulling the
handlebar away from the frame. and
pushing towards the floor until the stroller
clicks into place.
3 Place the stroller in the upright
position.
4 Snap the red Safety Strap to the
frame under the fold mechanism
WARNING: Ensure that all the locking
devices are engaged before use.
FRONT WHEEL
5 Installation
• Lay pushchair on its back so the
handlebar is resting on the floor.
• Attach the front wheel by sliding it into
the front wheel mount until it clicks.
Gently pull on the front wheel to make
sure it is properly attached.
6 Removal
• While pressing the front wheel release
button, gently slide the front wheel out of
the front wheel mount.
SWIVEL FEATURE
FOR WALKING ON UNEVEN TERRAIN IN
TRAILING MODE:
7 Gently pull the Swivel Lock into the
upright position until it clicks into
place.
FOR WALKING ON UNEVEN TERRAIN IN
LEADING MODE:
8 Push the swivel lock button down to lock
the front wheel to a fixed position.
9 Rotate Front Wheel until it clicks into
locked forward position
WARNING: When loading and unloading
child, lock the front wheel in a fixed
position. Although the front wheel of your
pushchair locks, it is not intended for
jogging or exercise purposes.
ALIGNMENT FEATURE
10 Should the stroller pull to one side while
the Front Wheel is locked in the fixed
position, use the Alignment Knob to align
If the stroller pulls to the right, turn the
knob left to adjust If it pulls to the left,
turn the knob right to adjust the stroller's
alignment.
NWL0000981309B Summit X3 EMEA R02.indd 11
REAR WHEELS
11 Installation
• Align the rear wheel axle with the wheel
mount on the pushchair frame and insert
it into the wheel mount until it locks into
place. You will hear a click.
• Gently pull on the rear wheel to make
sure it is properly attached.
12 Removal
• While pressing down on the wheel
release button, gently slide the rear
wheel out of the wheel mount.
BRAKE
13 To lock the brakes: push the brake lever
down to engage the brakes.
14 To release the brakes: lift the brake lever
up.
WARNING: Lock the brakes before
loading and unloading your child and
whenever the pushchair is not moving.
CANOPY
15 Attach the canopy to the frame:
Slide the canopy peg into the top
hole of the Accessory Mounting
Bracket until it clicks into place.
NOTE: When using a City Go i-Size/
Graco or Britax car seat, the canopy
must be in the top position. For all other
carseats, canopy must be removed.
16 At the top and on the side of the
Canopy, snap the webbing together
around the top of the frame on both
sides.
17 Secure the canopy by aligning the
Velcro® strips on the console and
canopy.
18 Remove the canopy: Press the top gray
button on the Accessory Mounting
Bracket to release the canopy peg and
unfasten snaps and Velcro® at the top of
the canopy.
ADJUSTING SAFETY HARNESS
19 From the back of the seat, undo the
fastening strip and open the pocket to
locate the plastic square stopper. Turn
stopper and pass through the openings
in the PE board and seat fabric.
