Do not connect the unused pins.
QUATECH DSC200/300
Signal
Pin
GND
3
TxD+
2
RxD+
4
TxD-
7
RxD-
8
8 Operation of the card
8.1 Different baud rate divisors
The table shows the divisor which need to be used at the certain baud rate (if no SICK MST
software is used).
Baud rate
9 600
19 200
38 400
500 000
8.2 Usage of LMSIBS User software
If you use the LMS/LMI user software, you have to define in the user software that a High-
Speed-interface card is used.
¾
In the menu "sensor-interface" choose the card type ".../1MBd" in the field of "Baud
rate/card type".
8.3 Usage of the MST200 Measurement Software Tool
If you use MST, you have to define in the user software that a High-Speed interface card is
used.
¾
Enter "Card Type" = "2" in the configuration file.
8 009 411/11-06-2001
LMS200/291
Signal
GND
RxD+
TxD+
RxD-
TxD-
Linkage
Linkage
Divisor
1 075
2 216
4 300
56 000
©SICK ⋅ AG ⋅ Auto Ident ⋅ Germany ⋅ All rights reserved
LMS 220/211/221
Pin
Pin
5
Shield
2
2
3
10
1
1
4
9
7
3
8
11
Remarks
9 600 Baud
19 200 Baud
38 400 Baud
500 kBaud
8/8
