SICK QUATECH Montageanleitung
SICK QUATECH Montageanleitung

SICK QUATECH Montageanleitung

Pc-high-speed schnittstellenkarte

Werbung

Verfügbare Sprachen

Verfügbare Sprachen

Montageanleitung zum Einbau und Betrieb der seriellen
QUATECH
PC-High-Speed Schnittstellenkarte
Fitting Instructions for the installation and operation of the
QUATECH
PC serial high-speed interface card

Werbung

Inhaltsverzeichnis
loading

Inhaltszusammenfassung für SICK QUATECH

  • Seite 1 Montageanleitung zum Einbau und Betrieb der seriellen QUATECH PC-High-Speed Schnittstellenkarte Fitting Instructions for the installation and operation of the QUATECH PC serial high-speed interface card...
  • Seite 2: Inhaltsverzeichnis

    Inhaltsverzeichnis / Contents List Seite / Page German Kartentyp und Lieferant........................3 Allgemeine Beschreibung der Karte/ Sicherheitshinweise .............. 3 Installation und Inbetriebnahme....................... 3 3.1 Vorgehensweise .......................... 3 3.2 Softwarekonfiguration und Parametrierung der Karte ..............4 3.3 Anschluss an den Scanner und Pin-Belegung der Karte und des Scanners....... 4 Betrieb der Karte..........................
  • Seite 3: Kartentyp Und Lieferant

    3 Installation und Inbetriebnahme 3.1 Vorgehensweise 1. PC ausschalten 2. Auf QUATECH-Karte Jumper setzen und in einen beliebigen freien Steckplatz einbauen 3. PC einschalten 4. Konfiguration ( siehe Abschnitt 3.2 ) ©SICK ⋅ AG ⋅ Auto Ident ⋅ Germany ⋅ All rights reserved...
  • Seite 4: Setzen Der Jumper Und Schalter Für Rs422

    X = nächster freier logischer COM-Port (z.B. /c3). Dieses Kommando sollte nur einmal ausgeführt werden, da bei jedem erneuten Aufruf Einträge in der Registry hinzugefügt werden, was zu Problemen führen kann. 6. PC neu starten. ©SICK ⋅ AG ⋅ Auto Ident ⋅ Germany ⋅ All rights reserved 8 009 411/11-06-2001...
  • Seite 5: Anschluss An Den Scanner Und Pin-Belegung Der Karte Und Des Scanners

    3.3 Anschluss an den Scanner und Pin-Belegung der Karte und des Scanners Die Pinbelegung der Ausgangsbuchse der QUATECH-Schnittstellenkarte für PCI-Bus ent- spricht nicht der Pinbelegung der MOXA-Karte EISA-Bus. Für die QUATECH-Karte ist die geänderte Verdrahtung zu beachten, falls vorher die MOXA-Schnittstellenkarte benutzt wur- de.
  • Seite 6: Type Of Card And Supplier

    The card is provided with a 16 MHz-quartz by the supplier in order to obtain a max. baud rate of 1 Mbaud. This is necessary to operate the SICK laser scanners of the LMS 2XX series without an ad- ditional evaluation unit. The max. baud rate of the scanners is 500 KBaud.
  • Seite 7: Software Configuration And Parameterisation Of The Card

    7.3 Connection to the scanner and pin reservation of the card and scanners The pin connection of the outputs by the Quatech Interface card for PCI Bus is not the same like the pin connection of the MOXA Interface card for EISA Bus. Please check the wiring carefully if you have used the MOXA Card before.
  • Seite 8: Operation Of The Card

    TxD- Linkage Linkage 8 Operation of the card 8.1 Different baud rate divisors The table shows the divisor which need to be used at the certain baud rate (if no SICK MST software is used). Baud rate Divisor Remarks 9 600...
