1. BASIC MAINTENANCE
INSTRUCTIONS
Everyone who is called upon to work on the
altek product must have read and understood
the operating instructions before starting. This
also applies to people who only carry out work
on the altek product occasionally.
Please also follow the manufacturer's ope-
rating instructions enclosed with other ele-
ments and components.
Accident prevention regulations and safety
rules issued by employers' liability insurance
associations and accident insurance providers
are also to be observed.

1.1. Symbols and notices

In these operating instructions you will come
across the following symbols and references:

The pointing finger prompts you to
 

perform an action.




The arrow shows you the result of

 your action.


⚠
WARNING

⚠
⚠

This notice warns about a dangerous situa-

tion which – if not avoided – may result in


death or serious injury.
⚠
 CAUTION



This notice warns about a dangerous situa-

tion which – if not avoided – may result in



slight or moderate injury.


⚠
ATTENTION




This notice warns about material damage.
⚠
ATTENTION - ENVIRONMENT


⚠
This notice warns about environmental
damage.

INFORMATION

This notice provides you with additional infor-
mation or tips.
© Altek GmbH, 02/2021 – 83651, Version (c)
Maintenance Piston Diaphragm Pumps

1.2. SYMBOLS ON THE ALTEK PUMP

Standard parameters / Type plate (1)
- Pump pressure (P in bar / psi)
- Pump rotation (N in min-1 / rpm)
- Flow rate (l/min / gpm)
- Pump type, Address of producer
Pressure accumulator (2)
- Spraying pressure (bar / psi)
- minimum required spraying pressure (bar
/ psi)
Oil (3)
- Pump type
- Oil type
- maximum filling capacity (l / oz)
