Specifications - Maker Factory 2108290 Kurzanleitung

Pinout / Pin Map
CAN
CAN_CS
CAN_INT
CAN_SCK
CAN_MISO
CAN_MOSI
I2C Interface
IIC_SDA
IIC_SCL

Specifications

Interfaces
CAN Controller
RS485 Transceiver
Dimensions (approx.)
Weight (approx.)
Disposal
Electronic devices are recyclable waste and must not be dis-
posed of in the household waste.
At the end of its service life, dispose of the product in
accordance with applicable regulatory guidelines.
You thus fulfill your statutory obligations and contribute to the pro-
tection of the environment.
ESP32 Chip
GPIO12
GPIO15
GPIO18
GPIO19
GPIO23
ESP32 Chip
GPIO21
GPIO22
2x I2C
1x CAN
1x RS485
1x TTL
MCP2515-1/SO
SP3485EN-L/TR
54 x 54 x 13 mm (W x D x H )
13 g
