Manual: PS-5200RGB / PS-9200RGB / PS-18.400RGB
NL NL NL
For third number (subnet) 0 or 1 is selectable. Set this by DIP switch at network card (advanced
users only!).
For fourth number (device address) select on network card a number between 100 and 115.
Don't set this value on PC (host) otherwise there is no communication possible.
Set for the subnet mask Subnetzmaske 255.255.255.0.
The values „Default gateway" and DNS-server-addresses are not relevant.
Summary:
- Computer address: last numeric keypad between 1 - 100 or 115 - 254
- Network address projector between 100 - 115 (see following chapter)
Connection establishment to the laser projector
To create a connection to projector, please open up your web browser and enter the IP address
of network card - by default its 192.168.0.100.
If communication works, following window appears:
Professional users can also create a connection to card by using a PING via control center.
Recognicing laser projector by system may take a few seconds (depending on PC and opera-
ting system). Therefore please wait a few seconds than start a map query .
