Commissioning; Mounting - Disty distybox 300 Bedienungsanleitung

1
1.1
Selecting a The distybox is designed for wall mounting in interior rooms. Please note
suitable that the device must not be fitted in the immediate vicinity of any other
location electronic devices such as hifi systems, office machines or microwave
ovens. This prevents any interference between the devices. In addition, the
device should not be installed near heat sources (e.g. radiators or in direct
sunlight). To prevent noise interference when making calls, the connected
terminal should not be positioned closer than one metre away from the
distybox.
Radio coverage The distybox must be able to establish a radio link to the DECT base
station. Before determining the final mounting position, you should
therefore check that your desired location is within the range of the DECT
base station.
Owing to the digital transmission in the frequency range used, there may
be radiowave "blind spots" even within the specified range, depending on
the nature of the building. This results in a loss of transmission quality.
However, just a small change in position will restore normal transmission
quality. As the distybox works as a cordless unit on your DECT base
station, you can use your cordless handset to check whether or not the
mounting position is suitable.
Wall mounting Follow the steps given below to install the distybox
1. Drill two 6 mm diameter holes into the wall at a distance of 60 mm
2. Insert the rawl plug and turn the screws until they are approx. 5 mm
3. Connect the external aerial to the
4. Connect the distybox to the power
5. Connect your terminal to the distybox.
6. Fit the distybox in place.

Commissioning

Mounting

apart.
away from the wall.
appropriate socket (distybox 5000 only).
supply.
5
Antenna plug
(distybox 5000 only)
60 mm
