TABLE OF CONTENTS
SR6100AT Receiver Diagram ....................................................................... 4
Powering the receiver with a separate receiver pack ..................................... 4
Powering the receiver with an ESC ............................................................... 4
SMART Throttle ........................................................................................... 4
AVC Receiver Installation ............................................................................. 5
Telemetry ................................................................................................... 6
Binding and Calibrating ............................................................................... 6
Bind and Calibration Process ....................................................................... 7
Disabling AVC Technology ............................................................................ 8
AVC Technology setup ................................................................................. 8
AVC TUNING ............................................................................................... 9
Receiver Firmware Updates ....................................................................... 11
2.4GHz Troubleshooting Guide ................................................................... 12
Telemetry Troubleshooting Guide ................................................................ 12
AVC Troubleshooting Guide ........................................................................ 13
FCC Information ........................................................................................ 16
Supplier's Declaration of Conformity ........................................................... 16
IC Information ........................................................................................... 17
Compliance Information for the European Union .......................................... 17
Specifi cations
Type
Dimensions (L × W × H)
Antenna Length
Channels
Weight
Band
Voltage Range
NOTICE: Digital servos are required with the SR6100AT AVC receiver. Using
analog servos with AVC technology will reduce the performance of the
system and may cause the servos to overheat.
The Spektrum™ SR6100AT AVC Telemetry Receiver is compatible with
all Spektrum DSMR® surface transmitters. Telemetry functions require
a Spektrum DSMR transmitter capable of telemetry, and SMART Throttle
telemetry may require a fi rmware update for your transmitter. Visit the product
page for your transmitter at SpektrumRC.com for more information.
TELEMETRY WITH SMART THROTTLE
With SMART Throttle the normal throttle lead delivers the throttle signal to
the ESC, plus the ESC can send telemetry data like voltage and temp back to
the receiver. For SMART Throttle to function you must use a SMART Throttle
ESC paired with a SMART Throttle telemetry receiver, and a Spektrum DSMR
transmitter with telemetry. Only certain Spektrum products include SMART
technology, check your ESC and transmitter manual for more information.
SR6100AT
DSMR AVC Receiver with Telemetry
42.4mm× 23.9mm × 15.1mm
120mm
6
10g
2404 MHz – 2476 MHz
3.5–9.6V
