faultless condition.
3. Always check for concealed electric cables
and gas and water pipes when drilling and
screwing in walls.

6. Operation

6.1 Charging the LI battery pack (Fig. 2-3)
1. Remove the battery pack (5) from the handle,
pressing the pushlock buttons (8) downwards
to do so.
2. Check that your mains voltage is the same as
that marked on the rating plate of the battery
charger. Insert the power plug of the charger
(6) into the mains socket outlet. The green
LED will then begin to ash.
3. Push the battery pack onto the battery char-
ger.
In section 10 “Charger indicator” you will nd a
table with an explanation of the LED indicator on
the charger.
If the battery pack fails to become charged, ple-
ase check
•
whether there is voltage at the socket-outlet
•
whether there is proper contact at the char-
ging contacts on the charger.
If the battery still fails to become charged, please
return
•
the charger
•
the battery pack
to our Customer Service Department.
To ensure that items are properly packaged
and delivered when you send them to us,
please contact our customer service or the
point of sale at which the equipment was
purchased.
When shipping or disposing of batteries and
cordless tools, always ensure that they are
packed individually in plastic bags to prevent
short circuits and res.
To ensure that the LI battery pack provides
long service you should take care to recharge
it promptly. You must recharge the battery pack
when you notice that the power of the cordless
screwdriver drops.
GB
6.2 Torque setting (Fig. 4 / Item 1)
Important! The tool must be at a standstill
when you set the torque with the setting ring.
The cordless screwdriver is tted with a
mechanical torque selector.
The torque for a speci c size of screw is selected
with the set-collar (1). The correct torque depends
on several factors:
•
on the type and hardness of material in
question
•
on the type and length screws used
•
on the requirements needing to be met by the
screwed joint.
The clutch disengages with a grating sound to
indicate when the set torque is reached.
6.3 Selector switch for driving/drilling/impact
drilling (Fig. 4/Item 11)
•
For driving purposes, set the selector switch
(11) to the „Screw“ position. The torque is
adjusted via the torque setting (1) (see point
6.2).
•
For drilling purposes, set the selector switch
(11) to the „Bit“ position. The slip coupling is
now off and the maximum torque is available
regardless of the torque setting (1).
•
For impact drilling purposes, set the selector
switch (11) to the „Hammer“ position. The slip
coupling is now off and the maximum torque
is available regardless of the torque setting
(1).
Important! Change the torque setting (1) and
the selector switch for driving/drilling/impact
drilling (11) only when the equipment is at a
standstill.
6.4 Forward/Reverse switch (Fig. 5 / Item 3)
With the slide switch above the On/O switch you
can select the direction of rotation of the battery-
powered drill/screwdriver and secure it against
being switched on accidentally. You can choose
between clockwise and anticlockwise rotation. To
avoid causing damage to the gearing it is advisa-
ble to change the direction of rotation only when
the tool is at a standstill. The On/O switch is blo-
cked when the slide switch is in centre position.
6.5 On/O switch (Fig. 5 / Item 4)
In nitely variable speed control is possible with
the On/O switch. The further you press the
switch, the higher the speed of the battery-powe-
red drill/screwdriver.
