Installation

Fig. B Determine the location for the UVC device in the filter. This must be below the water level of the filter and
sufficient water must be able to flow past it. The space should be sufficient for the quartz glass (± 35 cm).
• Drill a hole with a diameter of 50 mm, at the desired position into the wall of the filter.
• Loosen the lock nut (c) from the adapter (b).
• Undo the fastening nut (d) from the adapter.
• Insert the adapter into the hole, ensuring that the O-ring (j) is between the adapter and the filter wall (outside of
the filter).
• Tighten the fastening nut (d) back on the adapter on the inside of the filter so that the whole is securely fastened.
Fig. C Carefully unpack the UV lamp (g) and insert the lamp into the lamp holder (f).
• Remove the quartz glass (e) from the packaging and place the O-ring (h) correctly in the top of the quartz glass.
• Carefully slide the lamp and lamp holder into the quartz glass (e). Make sure that the micro-switch is in the recess.
The micro-switch is an extra security, it ensures that the UV lamp is always switched off automatically when
disassembling (in case you forgot to switch off the UV lamp).
• Slide the O-ring (i) over the plastic part of the quartz glass and carefully slide the assembly into the adapter.
• Make sure that the O-ring (i) remains in place between the edge of the adapter and quartz glass.
• Tighten the lock nut (c) hand-tight at the adapter, so that it is firmly in place.
• Check the whole assembly for possible leaks.
• Make sure that the UV lamp is completely submerged and the filter cover is closed before inserting the plug into
the wall socket.
• Install the ballast in a dry place (not on the ground), protected against splashing water, with a minimum 2 metre
clearing from the pond.
• Insert the plug into the socket so that the UV lamp lights up.
• Through the transparent viewing area of the lamp holder you can see if the UV lamp is lit.

Maintenance

• Remove the plug from the socket before carrying out maintenance!
• The UVC device should be cleaned twice a year. As soon as algae growth increases, check the UVC device and UV-
lamp and clean the whole or exchange the UV lamp (Art. 06010465) as needed.
• The lamp is hot, wait 10 minutes after switch off before opening the UVC device.
• Ensure that the water is drained out of the filter first, before removing the UVC device.
• Undo the lock nut (c) and remove the lamp holder (f) with the UV lamp (g) and the quartz glass (e) from the
adapter. If necessary, you can also replace the lamp.
• The High Output UV lamp has an effective life span of approximately 16,000 hours (±2 years). The lamp will still
burn beyond this period, but the UV radiation is no longer effective.
• Clean the quartz glass outer face with a soft cloth and SuperFish Pump & UVC Clean carefully. After cleaning,
thoroughly rinse the quartz glass with clean tap water and check for damage. Replace the quartz glass (Art.
06010474) if it shows any damage (to prevent glass breakage).
• Reinstall everything, making sure the O-rings are correctly positioned. Replace the O-rings (Art. 06010476) if they
are showing signs of perishing.
• Tighten the lock nut (c) hand-tight at the adapter.
• Check the whole assembly for possible leaks.
