This manual is addressed to qualified specialized staff having the technical skills and
expertise for mounting and commissioning as well as setting and installing of presses.
This manual is valid for the following products
Manual Rack and Pinion presses 2 HZP and 4 HZP
Overview
Hand lever
Depth block
Return stroke blocking
mechanism
Press ram
Press table
Not all components are
available for all types of
presses
The presses are exclusively intended to be used as technical working
Note:
equipment to accomplish the said types of work in the commercial or
industrial area by trained and skilled staff.
Any other use, especially by private consumers, or use exceeding that
specified is an infringement of use for intended purpose.
Scope of delivery:
Before mounting/commissioning please check delivery for
completeness and intactness. In case of parts missing or showing
visible damages please inform
:
GECHTER
GmbH.
Crank handle
clamp bolt height
adjustment
Guide unit clamping
Guide unit
Press stand
Mounting bores
