1. Operator control panel ( see page 6 )
2. Charging socket
3. Clean-water tank fill point
4. Floor-tool raise / lower lever
5. Clean-water tank emptying hose & fill level
6. Floor-tool vacuum hose
7. Brush deck-lifting Pedal

Machine Overview

3
8
7
9
10
8. Extra brush load Pedal
9. Semi parabolic floor-tool
10. Brush deck
11. 50 Amp battery fuse
12. Top tank (waste water)
13. Bottom tank (clean water)
14. Top tank hood
15. Waste water dumping hose
