Fitting the Floor Tool

Fig.7
Lower the floor-tool by moving the release lever to the lower position (Fig.7).
Push floor-tool onto the holder and secure with the easy-fit securing pin (Fig.8).
Push floor-tool hose onto the floor-tool; ensure hose is pushed down fully (Fig.9).
Note: Raise floor-tool again before driving to the cleaning area (Fig.10).

Fitting the brush

Use either a 550mm Brush or a 500 Pad.
Featuring the Nulock brush system.
The brush is simply pushed and twisted to lock, making fitting and removal a simple process.
Slide the brush / pad under the brush deck (Fig.11).
Fit the brush / pad onto the Nulock drive chuck, twist to lock the brush / pad in place (Fig.12).
Safety gloves are recommended for the changing of used brushes.
Machine Set Up
ALWAYS ENSURE THAT THE MACHINE IS SWITCHED OFF
BEFORE MAKING ANY ADJUSTMENTS
Fig.11
Fig.8
Fig.12
12
!
Fig.9
Fig.10
!
