5.
Test Mode
In test mode, you can set a static colour, or use changing colours at
different speeds.
Static Colour
To set a static colour:
1.
Set DIP switch 10 to ON.
2.
Set DIP switches 8 and 9 to OFF.
3.
Select the desired static colour by setting the corresponding DIP
switch (1-7) to on. If all DIP switches are off, all LED lights are
out. If more than one DIP switch is set to on, the DIP switch
with the highest value prevails:
Colour
Red
Green
Blue
Yellow
Purple
Cyan
White
0 = off; 1 = on; x = can be either on or off.
Changing Colours
To use changing colours:
1.
Set DIP switch 10 to ON.
2.
Choose the desired dynamic mode:
o For switching colours, set DIP switch 8 to on and DIP switch 9
to off.
o For fading colours, set DIP switch 9 to on (DIP switch 8 can
be either on or off).
3.
Set the speed of the colour change by setting the corresponding
DIP switch (1-7) to on. All DIP switches off = slowest; DIP
switch 7 on = fastest. If more than one DIP switch is set to on,
the DIP switch with the highest value prevails.
V. 01 – 12/09/2013
LEDC09
1
2
3
1
0
0
x
1
0
x
x
1
x
x
x
x
x
x
x
x
x
x
x
x
5
DIP switch
4
5
6
0
0
0
0
0
0
0
0
0
1
0
0
x
1
0
x
x
1
x
x
x
7
8
9
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
1
0
0
©Velleman nv
