Keep this device away from dust and extreme temperatures. Make
sure the ventilation openings are clear at all times.
Protect this device from shocks and abuse. Avoid brute force when
operating the device.
Familiarise yourself with the functions of the device before actually
using it.
All modifications of the device are forbidden for safety reasons.
Damage caused by user modifications to the device is not covered
by the warranty.
Only use the device for its intended purpose. Using the device in
an unauthorised way will void the warranty.
Damage caused by disregard of certain guidelines in this manual
is not covered by the warranty and the dealer will not accept
responsibility for any ensuing defects or problems.
Keep this manual for future reference.
4. Installation
Refer to the illustrations on page 2-4 of this manual.
1 DIP switches
2 DMX input
3 DMX output
4 DMX input
5 DMX output
6 terminals
V–
V+
COM
CH1
CH2
CH3
CH4
Caution: Use either 8P8C connectors or 3-pin XLR connectors. Do
not use both.
V. 01 – 12/09/2013
LEDC09
to select the operating mode
8P8C (RJ45) input from external DMX
controller
8P8C (RJ45) output to next LEDC09 device in
daisy chain connection
3-pin XLR input from external DMX controller
3-pin XLR output to next LEDC09 device in
daisy chain connection
to 12-24 VDC power supply (–)
to 12-24 VDC power supply (+)
to LED strip, power
to LED strip, red (channel 1)
to LED strip, green (channel 2)
to LED strip, blue (channel 3)
to LED strip, white (channel 4)
