Content Content....................... 2 Introduction ....................... 4 What is NAS? ....................4 Samba (Windows)................... 4 FTP....................... 5 NFS ......................5 More than a NAS ....................5 Printserver..................... 6 UPnP-AV......................7 Bonjour and iTunes Support ................8 Extensibility ....................8 Package content ....................8 Take a look at the IB-NAS2001................
Seite 3
Set up Windows, FTP access restrictions for a share........... 41 Set up NFS access rights................43 System Settings....................45 Network Setting ....................46 Time Setting ....................46 Restart or turn off the IB-NAS2001 remotely ............47 System Information ..................47 Disk Usage .....................
NAS is short for “Network attached Storage”, which is used to name a specialized device that offers mass storage towards a data network. SOHO NAS like the ICY BOX IB- NAS2001 are small devices that simply share data from HDDs to an Ethernet. There are many approaches;...
IP-Addresses (host addresses). More than a NAS The ICY BOX IB-NAS2001 is not only an easy to use network storage device. It is a truly double functional HDD box. It offers a complete USB 2.0 HDD access chipset, offering greater flexibility.
But the IB-NAS2001 is even more. You can print via Network or, if you like to distribute Musik or Videos via your network at home, the UPnP-AV protocol can do this directly to your network media player. And if that still is not enough: The IB-NAS2001 can be additionally extended by other Applications.
UPnP-AV Netzwerk The included Twonky Media Server (30 days trial version) adapts this standard to as many players as possible. The Twonky Media Server has been updated several times a year so far to ensure compatibility to all new players. Therefore we have chosen to not implement this software fix in the firmware of the IB-NAS2001 but to give the user to easily upgrade it when a new version is released.
Bonjour and iTunes Support Netzwerk The IB-NAS2001 is able to assign its services via Bonjour, so that MAC computer can easily be connected to the server functions of the IB-NAS2001. Due to the iTunes support, multimedia files can be accessed via iTunes from anywhere in the network. Extensibility The IB-NAS2001 can arbitrarily extended on applications by installing additional software packages.
Take a look at the IB-NAS2001 Front Indicator LEDs On/off switch On the front side of the IB-NAS2001 there is the Switch for turning it on and off. Also in the front in one of the corners are the indicator LEDs located, indicating the most important operation states.
Back Power adaptor connector USB interface to PC USB host interface Network interface Button for reset to factory settings. Caution: You will loose all data! Downloaded from www.Manualslib.com manuals search engine...
Usage as external Storage drive First come first serve To use the Icy Box IB-NAS2001 as an external storage enclosure all is required is to connect to the USB interface of a computer. The decision whether the IB-NAS2001 is operating as an external storage case or as a NAS is determined by the first come first serve principle.
DHCP server. In case the DHCP server updates this information automatically to the DNS Server (see RFC 2136). The ICY BOX IB-NAS2001 could be accessed by simply entering “http://icybox” in the address line of a standard web browser. Continue with point “Using the management interface”...
DHCP controlled Network without automatic DNS update In a DHCP controlled Network environment the IB-NAS2001 gets its IP Address from the DHCP server. If the DHCP server does not update that information to the DNS server the necessary name resolution for entering “http://icybox” will not work because the DNS server has no information about the actual IP Address of the IB-NAS2001.
Not configured Network / Direct Attachment If the IB-NAS2001 is attached to a not configured network where no DHCP server provides the IP configuration (or the IB-NAS2001 is directly attached to the computer) and the computers are configured to use DHCP (which is default setting) the IB-NAS2001 will activate its own DHCP Server with the default IP Address 192.168.0.1 and will provide IP Addresses in a range from 192.168.1.2 till 192.168.1.50 with a net mask 255.255.255.0, which is part of the subnet...
Seite 15
IB-NAS2000 is found The actual IP Address configuration of the IB- NAS2000 is displayed Click on “OK” to continue Enter the password of the IB-NAS2000. Default password is “admin”. Click on “OK”. The current IP Settings are displayed. Select “Set IP configuration manually”...
Seite 16
Select your time zone Set the date and time manually or … … select a time server (requires an internet connection) Click on “Next” Click on “Save” Click on “OK” Downloaded from www.Manualslib.com manuals search engine...
Click on “Exit” After the procedure, the IB-NAS2001 could be accessed by typing “http://192.168.1.100” in the address line of the web browser. Continue with point “Using the management interface” for setting up the IB-NAS2001 on page 17. Using the management interface When entering the URL as mentioned in the points above in the address line of the web browser, for example “http://192.168.1.100”...
Logging In This is password protected. The administrative user name is “admin” and the default password is also “admin”. Enter “admin” as Username Enter “admin” as Password (default setting) Click on “Login” Management interface structure After successfully logged in the management surface is displayed. The management surface is structured in the main menu tab, the sub menu column and the setting’s space.
items when selected. On other browsers the menu tree will be displayed showing all subsidiary items always. Chosen Items are highligh ted in white color when selected. Hard disk initialization The first step in the setup of the IB-NAS20 01 should be the initialization of the hard disk. This is necessary because the IB-NAS2001 saves some settings in specialized system partitions on the hard disk.
OS file system accessibility via USB File system Operating systems capable accessing via USB EXT2 • Linux EXT3 • Linux FAT32 • Windows (98,NT, ME, 2000, XP, 2003) • OS X (Mac) • Linux File system features File system Features EXT2 •...
Disk Utility You can find the hard disc initialization settings on: Control Panel Maintenance Disk Utility Command button for formatting the disk File system selector Command button for unmounting the disk Command button for refreshing the display The Disk Utility dialogue shows up a table containing the following information: Column Description Device name...
Seite 22
Initializing the hard disk is done in two steps: First choose a file system for the data partition and second click on “Format” button: Attention: The choice of the file system has big influence on the features provided by the NAS. Also important is the fact that not all file system types could be read by every operating system.
Seite 23
When the formatting process is completed the IB-NAS2000 needs to restart. Please, do not interrupt this process! After the restart it is necessary to log in again Enter “admin” as Username Enter “admin” as Password (default setting) Click on “Login” Downloaded from www.Manualslib.com manuals search engine...
Seite 24
The sub menu column has now several new items, which are not displayed as long as the hard disk hasn’t been initialized Select Control Panel Maintainance Disk Utility As you can see the entries in the Table have been changed Also can be chosen after which time of inactivity the disk is set to an...
Changing the admin password To change the admin password please select: Personal Info Personal Information Account Enter new admin password here and retype it again in the line below The language of the menus can be changed here Optional a description to the admin account could be entered Clicking on “Refresh”...
User Management The user management could be found selecting: Control Panel Users and Groups User Management List of existing users Field for user name Field for password Field for a description Checkmark inducing to create a private folder (share) Control button to delete user Control button change to group membership form...
Create a new user To create a new user simply fill out the form and click the “Save” Button. The next example shows a procedure setting up a new user with the user name “testuser” and the password “test”. The user should also have a private folder, which is a special folder just for his private use, which is only accessible or even displayed by the one who identifies with that particular username and password.
Change User settings To Change a user setting open the “User Management” form: Control Panel Users and Groups User Management Then all detailed settings of the user are displayed and can be changed. Select an existing user The entry in the “Password”...
Assign a single user to one or more groups As you have seen the “User Management” form has a button called groups. If you select a user in the “Existing Users” list and click on that button a form for adding the selected user to all existing groups is opened.
Select the group to be added to. If you want to select more than one hold the <CTRL> key pressed while selecting Click on “<<Add” button Click on “Save” button to save changes Remove a single User from one or more Groups In a similar way a user is removed from one or several groups Select an existing user Click the “Groups”...
Seite 31
Select the group the User should be removed from. If you want to select more than one hold <CTRL> key pressed while selecting Click on the “Remove>>” button to remove the user from selected groups Click on “Save” button to save changes Downloaded from www.Manualslib.com...
Group Management The group management could be found selecting: Control Panel Users and Groups Group Management List of existing groups Field for group name Control button to delete group Control button to change to members form Control button to reset form Control button to save changes...
The group is created and added to the “Existing Groups” list Delete a group To delete one or more groups, mark them in the “Existing Groups” list and click on the “Delete Group” button. Select the group to be deleted. If you want to select more than one hold <CTRL>...
Add one or more Users to a single Group To add one ore more Users to a Group you do not need to open each User one by one to add them to a group. When you select the Group you want the users to be added to in the “Existing Groups”...
Remove one or more Users from a single Group To remove one or several user from a particular group you also just have to select the Group you want the users to be deleted from in the “Existing Groups” list and the “Group Members”...
File Server Settings What is a file server? – A file server offers disk space to a network. The term server used to name a service offered to the network. As described in point “What is NAS?” (page 4) the IB-NAS2001 uses 3 different services to provide hard disk space to the network: Samba (Windows), FTP and NFS.
browsing the windows network. If the windows network has a WINS server for providing a network directory, the IP Address could be specified here. FTP Server Settings Aside of the possibility to enable or disable the FTP service, the port number of that server could be modified in order to accommodate a possible port forwarding of a...
Seite 38
Attention: To be able to set a quota the EXT3 file system has to be chosen for the data partition, because only the EXT3 file system supports that feature. If the data partition is formatted with EXT2 or FAT32, this option can not be selected.
Share Management In this section of the web management surface is defined how the HDD storage is offered to the network. Here you can create folders, so called shares, and define the access rights for the different users or groups towards it. For each folder created here the Windows (Samba), FTP and NFS Access can be defined and restricted.
Creating a new share To create a new share please enter a share name and click on the “Save” button. Enter the new share’s name Enter a comment Click on the “Save” button to save changes How to set up your computer to access a share on the IB-NAS4220-B is described in point “Mapping shares and Printers”...
Set up Windows, FTP access restrictions for a share To set up the Windows and FTP access restrictions for a share, select the share you wish to restrict in the “Existing Shares” list and change to the Windows and FTP access form. Select the share to be managed.
Seite 42
To grant rights on user level select the user or group you want to give rights in the “No Access” list and whether click on the “<< Read Only” button to give him or it read only rights or click on the “<<Writable” button to give him or it all rights. Select user or group you want to grant all rights Click on “<<Writable”...
Select the user or group you want to revoke rights from Click on the “Remove>>” button Click on the “Save” button to save changes How to set up your computer to access a share on the IB-NAS4220-B is described in point “Mapping shares and Printers”...
Seite 44
Select the „Allow for all“ check button to grant NFS access to any host Click on the “Save” button to save changes To allow access to a special IP Address or a Subnet select the referring radio button, enter the values and click on the “Save” button. To give access to a single IP Address, select this radio button...
To revoke the rights for singular IP Addresses or subnets select them in the “Allowed IP/Subnet” list, click on the “Remove” button and click on the “Save” button to save changes. Select the IP Address or Subnet to be revoked Click on the “Remove”...
Network Setting The Network settings as described in point “Network configured on fix IP-Addresses” (page 14) can also be set via the web surface. Additionally the network name of the IB- NAS2001 could be changed there. To access the referring form, please select: Control Panel System Network Setting...
Restart or turn off the IB-NAS2001 remotely In some cases it might be necessary to restart or even turn off the IB-NAS2001. This could be done via the web interface. To access the referring form, please select: Control Panel System Turn off Server To restart or turn off the IB-NAS2000, please click...
Disk Usage To get a quick overview of the used and free space please select: Control Panel System Disk Usage For a brief overview on the usage of the complete disk, select “Summery” as described below. If “Summary” is selected here a short overview of the usage of the complete disk is...
Network Service The IB-NAS2001 offers a variety of other Network services such as sharing Pictures, Music and Videos to the local network, DHCP or Downloading/Sharing files over the internet. The following Table gives you a quick overview: Network Service Description DHCP A DHCP server allows configuring all network devices in a subnet automatically and centralized.
automatically its DHCP Server, distributing IP-Addresses from 192.168.1.2 to 192.168.1.50 with a Maximum Lease Time of 1 day. This behavior ensures an easy auto configuration of the IB-NAS2001-B in a Network with no auto configuration infrastructure. Manual DHCP configuration To access the manual setup of the DHCP server select: Control Panel Network Service DHCP Server...
DHCP Setting Description Secondary DNS An alternative DNS server. Other DNS Another alternative DNS server. DHCP IP Address Start Start of the range of IP-Addresses which form the pool out of that the DHCP server distributes the IP-Addresses to the asking clients. DHCP IP Address End End of the IP-Address range.
Bonjour (including iTunes support) Bonjour is a protocol to distribute service information among network devices. This protocol is mainly used by Mac computers. Enabling the support of this protocol simplifies the use together with Mac computers. If Bonjour is enabled, the iTunes support could be enabled too.
If you download the latest version of Twonky Media from the homepage mentioned above you might have to unpack the downloaded file first to disk of your local computer and then copy the resulting “twonkymedia” directory to the “applications” directory in the “public”...
The Twonky Media User Interface will be displayed in another browser window. Using Twonky Media At the beginning Twonky Media will scan your complete IB-NAS2001-B for media content, such as music, pictures or video files. Twonky is preset to work instantly out of the box. For details on activating, licensing or how to use Twonky Media, pleas visit Twonky Visions (Manufacturer of Twonky Media) Homepage: http://www.twonkyvision.com...
aintenance In this section the subm enu Maintenance is described. The Maintenance submenu bundles tools for the hard disk setup (described already in point “Disk Utility”), firmware upgrade, save or restore the configuration and a factory reset. Firmware Upgrade The IB-NAS2001 is constructed to allow a complete upgrade of the firmware. The firmware upgrade form can be found selecting: Control Panel...
After the restart it is necessary to log in again Save and restore configuration The IB-NAS2001 offers an opportunity to save all settings been made to disk and restore them if necessary. Save configuration You will find the form for saving the configuration by selecting: Control Panel Maintenance Save Configuration...
Restore Configuration You will find the form for restoring the configuration by selecting: Control Panel Maintenance Restore Configuration To restore all configuration, please click on the “Browse…” button. A dialogue is opened where you can select the configuration file. Click on the “Restore” button to start the restore process.
USB-Sticks and USB hard discs The IB-NAS2001-B can be extended with external USB mass storage devices, such as USB-Sticks or USB hard discs. The IB-NAS2001-B so far supports up to 2 external storage devices, since it has 2 USB 2.0 interfaces. If one of these interfaces is already used for a USB Printer the IB-NAS2001-B supports only one USB mass storage device.
Installation of an application The installation of an application is pretty simple. The referring installation file has just to be copied in the “new_software” folder in the “applications” folder in the “public” share, and the IB-NAS has to be rebooted. Attention: After the upgrade described above the HDD needs to be initialized in order to grant that the appropriate folders are generated on the HDD.
Mapping shares and Printers Mapping Windows shares in Windows To access the IB-NAS2001 shares in windows proceed as described below: Right click on “My Computer” Click on “Explore” Enter “\\icybox” in the address line of the Windows Explorer, where icybox is the name of the IP-NAS1000 and hit “...
Seite 61
Enter the user name defined while creating a new user here Enter the referring password defined while creating a new user here Click on “OK” All shares offered by the IB-NAS2000 are now listed here To map this share now permanently to the local computer, right click on Downloaded from...
Seite 62
Click on “Map Network Drive…” Select the letter you want to map the share to Click on “Finish” to complete the mapping From now on you can find and access the share here via the Letter assigned to Downloaded from www.Manualslib.com manuals search engine...
Mapping the printer in Windows To map the printer in Windows go Click on “Start” and selec t “Printers and Faxes”. Select “Add a printer” Click on “Next >” Downloaded from www.Manualslib.com manuals search engine...
Seite 64
ect “A network printer, or a printer attached to another computer” Click on “Next” Select “Connect to this printer…” Enter “\\icybox\lp”, where icybox is the name of the NAS Select “Next >” Click on “Yes” Click on “OK” Downloaded from www.Manualslib.com manuals search engine...
Seite 65
Select a printer from the dialogue or … … select “Have Disk…” to select a driver from a disc Click on “OK” Click on “Finish” Now the printer is installed and can be uses as directly attached to the computer. Repeat this procedure on all computers in your local network and yo u can use the pri nter from...
Mapping Windows shares on Mac OS X To map windows shares on Mac OS X proceed as described below: Open the Finder Select “Network” The IB-NAS2001 is displayed with its name Double click on “ICYBOX”, where ICYBOX it the name of theIB- NAS2001 Select the share you want to map...
The share is now accessible on the desk Mapping the Printer on Mac OS X Open the “Printer Setup Utility” by selecting the Menu “Go” and than “Utilities”: Open „Printer Setup Utility“ Click on “Add” Click on “OK” Downloaded from www.Manualslib.com manuals search engine...
Seite 68
Select “Windows Printing” Select the workgroup name of the IB-NAS2001, default: “WORKGROUP” Select “icybox” where icybox is the name of your IB-NAS2001 Select the printer model Click on “Choose” Enter user name and password of a user defined for the IB-NAS2001 Click on “OK”...
Mounting Windows shares in Linux To mount the windows shares in Linux open a shell and type (<IP Address>= IP Address of the IB-NAS2001, <share>=Windows share of the IB-NAS2001, <user>=username, <pass>= password, <mountpoint>= path of the mount directory): mount –t smbfs //<IP Address>/<share>...
Benchmark Conditions RaidSonic IB-NAS1000, IB- NAS4220-B, IB-NAS2000, IB-NAS2001 Firmware You may conduct internal benchmark testing of the firmware of the models IB-NAS1000, IB-NAS4220-B, IB-NAS2000 and IB-NAS2001. You may disclose the results of any benchmark test of the of the firmware of the models IB-NAS1000, IB-NAS4220-B, IB- NAS2001 and IB-NAS2000, provided that you comply with the following terms: (1) you must disclose all the information necessary for replication of the tests, including complete and accurate details of your benchmark testing methodology, the test scripts/cases,...
Seite 71
Version D 1.8.13 Downloaded from www.Manualslib.com manuals search engine...
Seite 72
Inhalt Inhalt ......................... 2 Einführung......................4 Was ist NAS? ....................4 Samba (Windows)................... 4 FTP....................... 5 NFS ......................5 Mehr als NAS ....................5 Printserver..................... 6 UPnP-AV......................7 Bonjour und iTunes Support ................8 Lieferumfang ...................... 8 Das Äußere des IB-NAS2001 ................9 Die Frontansicht ....................
Einführung Was ist NAS? NAS ist die Abkürzung für “Network Attached Storage” und wird gebraucht um Geräte zu bezeichnen, die Massenspeicher in einem Netzwerk anbieten. SOHO NAS wie das IB- NAS2001 sind kleine Geräte, die Daten von einer Festplatte im Netz zur Verfügung stel- len.
Router Netzwerk Das FTP Protokoll ist eine der ältesten Arten der Dateiübertragung im Internet. Es ist schnell und bietet einen einfachen Zugriff auf die Festplatte auch über das Internet. Es existiert eine große Menge an Softwareclients auch für die exotischsten Betriebssysteme, die dieses einfache aber schnelle Protokoll verwenden.
Aber das IB-NAS2001 ist mehr. Sie können via Netzwerk drucken oder, wenn sie Musik, Bilder oder Videos über ihr Netzwerk zuhause übertragen wollen, dies mit dem UPnP-AV Protokoll direkt mit ihrem Netzwerkmediaplayer tun. Und wenn das immer noch nicht reicht: Das IB-NAS2001 kann beliebig um weitere Appli- kationen erweitert werden.
UPnP-AV Netzwerk Der im Lieferumfang enthaltene Twonky Media Server (30 Tage Testversion) passt diesen Standard an so viele Netzwerkmediaplayer wie möglich an. Der Twonky Media Server wird von Twonky Vision mehrmals im Jahr auf den neuesten Stand gebracht, um die Kompatibilität mit möglichst vielen Playern zu gewährleisten.
Bonjour und iTunes Support Netzwerk Das IB-NAS2001 ist in der Lage seine Netzwerkdienste per Bonjour zu annoncieren, so dass MAC Computer leichter die Verbindung zum IB-NAS2001 herstellen können. Dank des iTunes Supports können Multimediadateien von überall im lokalen Netzwerk per iTu- nes abgespielt werden.
Das Äußere des IB-NAS2001 Die Frontansicht Anzeige LEDs Lüfter Ein-/Ausschalter Auf der Frontseite des IB-NAS2001 befindet sich der Schalter zum Ein- bzw. Ausschalten des Geräts. Außerdem noch in einer Ecke die LEDs zur Anzeige der wichtigsten Betriebs- zustände. Beschreibung Stromnetz NAS Modus USB Modus Festplattenzugriff...
Rückseite Stromadapteranschluss USB Schnittstelle zum PC USB Hostschnittstelle Netzwerk Schnittstelle Knopf zum Rücksetzen in den Auslieferungs- zustand. Vorsicht: Alle Daten gehen verloren! Downloaded from www.Manualslib.com manuals search engine...
Gebrauch als externes Festplattenlaufwerk First come – first serve Um das ICY BOX IB-NAS2001 als externes Festplattenlaufwerk zu nutzen muss es ledig- lich über die USB Schnittstelle angeschlossen und eingeschaltet werden. Ob das IB- NAS2001 als externes Festplattengehäuse oder als NAS arbeitet wird dadurch entschie- den, welche Schnittstelle angeschlossen ist, wenn das IB-NAS2001 eingeschaltet wird.
Die folgenden Möglichkeiten existieren: DHCP gesteuerte Netzwerkkonfiguration mit automati- schem DNS Update In einer DHCP kontrollierten Netzwerkumgebung wird der ICY BOX IB-NAS2001 die IP- Adresse über einen DHCP Server zugewiesen. Wenn der DHCP Server diese Information automatisch beim zuständigen DNS Server einträgt (siehe RFC 2136) kann das IB-...
DHCP gesteuerte Netzwerkkonfiguration ohne automati- sches DNS update In einem Netzwerk in dem die Netzwerkkonfiguration über einen DHCP Server vergeben wird bekommt das IB-NAS2001 die IP-Adresse vom DHCP Server zugewiesen. Wenn der DHCP Server diese Information nicht bei dem zuständigen DNS Server aktualisiert, funk- tioniert die notwendige Namensauflösung für „http://icybox“...
Nicht konfiguriertes Netzwerk / direkt angeschlossen Wenn das IB-NAS2001 an ein nicht konfiguriertes Netzwerk angeschlossen wird, in dem kein DHCP Server die IP-Konfiguration liefert (oder das IB-NAS2001 direkt an den Com- puter angeschlossen wird) und die Computer (der Computer) eingestellt sind, die IP- Adresse per DHCP zu beziehen (Voreinstellung), dann wird das IB-NAS2001 seinen eige- nen DHCP Server aktivieren mit der voreingestellten IP-Adresse 192.168.1.1 und wird IP- Adressen aus dem Bereich von 192.168.1.2 bis 192.168.1.50 mit einer Netzwerkmaske...
Mit festen IP-Adressen konfiguriertes Netzwerk In einem Netzwerk, in dem kein DHCP Server zur Verfügung steht und alle IP-Adressen manuell und fest vergeben sind, zum Beispiel aus einem Bereich zwischen 192.168.1.2 und 192.168.1.254 mit einer Netzwerkmaske von 255.255.255.0 und 192.168.1.1 als Standardgateway und DNS Server, muss die IP-Adresse etc.
Seite 86
Anzeige der aktuellen IP- Einstellungen “Set IP configuration manually” auswählen “192.168.1.100” bei „IP Address“ eingeben, “255.255.255.0” bei „Subnet Mask und “192.168.1.1” je bei „Ga- teway“ u. DNS Server Auf „Next“ klicken Zeitzone wählen Zeit/Datum manuell ein- geben oder … … einen der Zeitserver wählen (benötigt eine Internetverbindung) Auf „Next“...
Seite 87
Auf „Save“ klicken Auf „OK“ klicken Auf „Exit“ klicken Nach diesen Einstellungen kann das IB-NAS2001 durch Eingabe von „http://192.168.1.100“ in die Adresszeile des Webbrowsers erreicht werden. Fortsetzung mit „Gebrauch der Managementoberfläche“ auf Seite 18 um das IB-NAS2001 einzurich- ten. Downloaded from www.Manualslib.com manuals search engine...
Gebrauch der Managementoberfläche Wenn die URL wie in den obigen Punkten angegeben in den Webbrowser eingegeben wird, zum Beispiel „http://192.168.1.100“, verbindet sich der Webbrowser mit dem IB- NAS2001 und stellt die Managementoberfläche des IB-NAS2001 dar. Anmelden Die Managementoberfläche ist Passwortgeschützt. Der administrative Benutzername ist „admin“...
Struktur der Managementoberfläche Nach erfolgreicher Anmeldung wird die Managementoberfläche angezeigt. Die Manage- mentoberfläche gliedert sich in die Hauptmenüzeile, die Untermenüspalte und den Konfi- gurationsbereich. Hauptmenüzeile Untermenüspalte Konfigurationsbereich In der Hauptmenüzeile kann unter den folgenden Punkten gewählt werden Auswahl Hauptmenüzeile Beschreibung Control Panel Alle Einstellungen bezüglich der Administration Personal Info...
Achtung: Das IB-NAS2001 benötigt diese besondere Struktur der Festplatte um ordnungsgemäß als NAS funktionieren zu können. Diese Struktur kann nicht manuell erzeugt werden, wenn das IB-NAS2001 als externes Fest- plattengehäuse arbeitet. Um das IB-NAS2001 in korrekter Weise als NAS verwenden zu können, müssen die notwendigen Schritte über den „Disk Utility“...
Filesystem Fähigkeiten FAT32 • Schreibschutz • Archive Bit • Unicode Dateinamen Filesystem Begrenzungen erlaubte Zei- max. Län- chen beim Fi- max. Pfad- max. Fi- max. Filesystem ge Filname lenamen länge legröße Größe EXT2 255 byte jedes Byte au- kein Limit 2 TiB 32 TiB ßer NUL...
Seite 92
Spalte Beschreibung Type Filesystem der Datenpartition Size Größe der Festplatte Used Größe des benutzten Anteils Mount Point Mount Point der Datenpartition im Unix Verzeichnisbaum Status Festplattenstatus Format Kommando Button zum initialisieren und formatieren der Festplatte Scandisk Kommando Button zum überprüfen und reparieren der Festplatte Umount Kommando Button zum inaktivieren der Festplatte...
Seite 93
Auf “OK” klicken Der Status wechselt auf „formatting“ Wenn die Formatierung beendet ist, muss das IB-NAS2000 neu starten. Bitte diesen Prozess nicht unterbrechen! Downloaded from www.Manualslib.com manuals search engine...
Seite 94
Nach dem Neustart ist eine erneute Anmeldung notwendig „admin“ als „Username“ eingeben „admin“ als Passwort eingeben (Voreinstel- lung) Auf „Login“ klicken Die Untermenüspalte hat mehrere neue Einträge, die nicht angezeigt wer- den, solange die Fest- platte nicht initialisiert ist Downloaded from www.Manualslib.com manuals search engine...
Seite 95
Nun wähle man: Control Panel Maintainance Disk Utility Wie man sehen kann haben sich die Einträge in der Tabelle geändert. Außerdem kann be- stimmt werden, nach welcher Zeit der Inaktivi- tät die Festplatte in ei- nen Energiesparmodus versetzt wird Downloaded from www.Manualslib.com manuals search engine...
Ändern des Administrator Kennwortes Um das Administratorkennwort zu ändern wähle man: Personal Info Personal Information Account Eingabe und Bestätigung durch erneute Eingabe des neuen Kennwortes hier Die Sprache der Menüs kann hier ausgewählt werden Eine optionale Beschrei- bung kann hier eingege- ben werden „Refresh“...
Benutzerverwaltung (User Management) Die Benutzerverwaltung findet man unter: Control Panel Users and Groups User Management Existierende Benutzer Eingabe Benutzernahme Eingabe Passwort Für Kurzbeschreibung Veranlasst Erzeugung eines persönlichen Netz- laufwerks Button zum Löschen des Benutzers Wechsel zum Gruppen- verwaltungsdialog Rücksetzen des Formu- lars Button zum Ausführen der Änderungen...
Seite 98
in Anspruch genommen werden kann auf 1000 MByte begrenzt werden, durch setzen einer Quota. Achtung: Um eine Quota setzen zu können, muss die Datenpartition mit dem EXT3 Filesystem formatiert sein, da nur dieses Filesystem dieses Merk- mal unterstützt. Wenn die Datenpartition mit EXT2 oder FAT32 forma- tiert wurde, steht diese Auswahl nicht zur Verfügung.
Ändern der Benutzereinstellungen Um die Benutzereinstellungen zu ändern öffnen Sie die Benutzerverwaltung (User Mana- gement): Control Panel Users and Groups User Management Wenn der ensprechende Benutzer ausgewählt wird werden alle zugehörigen Einstellungen angezeigt und können geändert werden. Auswahl des Benutzers Der Eintrag im „Pass- word“...
Einen existierenden Benutzer einer oder mehreren Gruppen zuordnen Wie bereits erläutert kennt das Formular für die Benutzerverwaltung einen Button „Groups“. Durch Auswahl eines Benutzers und klicken auf diesen Button gelangt man zu einem Formular zum hinzufügen dieses Benutzers zu bereits existierenden Gruppen. Benutzer auswählen Mit „Groups“...
Seite 101
Auswahl der Gruppe, zu der der Benutzer hinzu- gefügt werden soll. Zur Mehrfachauswahl <Strg> halten Auf „<<Add“ klicken „Save“ nimmt die Ände- rungen vor Downloaded from www.Manualslib.com manuals search engine...
Einen Benutzer aus einer oder mehreren Gruppen entfernen Auf ähnliche Weise wird ein Benutzer auch wieder aus einer oder mehreren Gruppen entfernt. Auswahl des Benutzers Mit „Groups“ gelangt man zu dem Formular zum Zuordnen Das Zuordnungsformular wird geöffnet. Auswahl der Gruppe von der der Benutzer entfernt werden soll.
Gruppenverwaltung (Group Management) Die Gruppenverwaltung erreicht man über: Control Panel Users and Groups Group Management Existierende Gruppen Feld für Gruppenname Button zum Löschen der ausgewählten Gruppe Button zum Wechsel zum Zuordnungsformular Rücksetzen des Formu- lars Button zum Ausführen der Änderungen Downloaded from www.Manualslib.com manuals search engine...
Eine neue Gruppe anlegen Um eine Gruppe anzulegen ist es nur notwendig, den Gruppennamen einzugeben und auf den „Save“ Button zu klicken. Hier den Gruppennamen eingeben Mit „Save“ wird die ent- sprechende Gruppe er- zeugt Die Gruppe wird erzeugt und zu den existierenden Gruppen hinzugefügt Downloaded from www.Manualslib.com...
Eine Gruppe löschen Um eine Gruppe zu löschen wird diese lediglich ausgewählt und auf den „Delete Group“ Button geklickt. Eine existierende Gruppe auswählen. Mehrfach- auswahl durch halten der <Strg> Taste. Auf den „Delete Group“ Button klicken um die Gruppen zu löschen Downloaded from www.Manualslib.com manuals search engine...
Einen oder mehrere Benutzer zu einer Gruppe hinzufügen Um einen oder mehrere Benutzer zu einer Gruppe hinzuzufügen, ist es nicht notwendig jeden Benutzer einzeln zu bearbeiten und einer Gruppe hinzuzufügen. Es ist viel einfa- cher in der Gruppenverwaltung die entsprechende Gruppe auszuwählen und auf den „Members“...
Einen oder mehrere Benutzer von einer Gruppe entfernen Um einen oder mehrere Benutzer von einer Gruppe zu entfernen, muss man ebenfalls nicht jeden Benutzer einzeln bearbeiten. Das kann ebenfalls über den oben beschriebe- nen Dialog erfolgen, in dem man die entsprechenden Benutzer auswählt und den „Remo- ve>>“...
verschiedene Dienste an um Festplattenplatz im Netzwerk anzubieten: Samba (Win- dows), FTP und NFS. Die grundlegenden Einstellungen bezüglich dieser 3 Dienste werden unter „File Server“ im „File“ Untermenü vorgenommen. Control Panel File File Server Alle drei Server können einzeln abgeschaltet werden. Das „File Server Settting“ Formular teilt sich in 4 Teile: Teil Beschreibung...
werk einen WINS Server hat, der die eine Art Netzwerkverzeichnis führt, kann hier e- benso seine IP-Adresse angegeben werden. FTP Server Setting Neben der Möglichkeit, den FTP Server an- bzw. abzuschalten, kann hier die Nummer des Ports dieses Dienstes verändert werden, um ihn einem möglichen Portforwarding nes Internet Access Routers, der NAT nutzt, anzupassen.
Seite 110
Zusätzlich zum Ein- bzw. Ausschalten dieser Funktion kann auch noch eine Quota für den Gastzugang definiert werden um die Menge des genutzten Festplattenplatzes zu begren- zen. Achtung: Um eine Quota setzen zu können, muss die Datenpartition mit dem EXT3 Filesystem formatiert sein, da nur dieses Filesystem dieses Merk- mal unterstützt.
Freigabenverwaltung (Share Management) In diesem Abschnitt der Managementoberfläche wird definiert, wie der Festplattenplatz dem Netzwerk angeboten wird. Hier werden Ordner erzeugt, so genannte „Shares“ und die Zugriffrechte auf diese für verschiedene Benutzer und Gruppen vergeben. Für jeden Ordner, der hier erzeugt wird, kann der Netzwerkzugriff über Windows (Samba), FTP und NFS definiert und entsprechend eingeschränkt werden.
Anlage einer neuen Freigabe (Share) Um eine neue Freigabe (Share) zu erzeugen, muss lediglich der Name eingegeben wer- den und auf den „Save“ Button geklickt werden. Namen der neuen Frei- gabe eingeben Mögliche Beschreibung Mit „Save“ die Änderung speichern Wie man auf eine Freigabe auf dem IB-NAS2001 vom Computer aus zugreift, ist in Punkt „Netzlaufwerke und Drucker verbinden“...
Definition der Windows und FTP Zugangsbeschränkungen für eine Frei- gabe (Share) Um die Windows und FTP Zugangsbeschränkungen zu setzen, wird lediglich die entspre- chende Freigabe ausgewählt und auf den „Windows, FTP Access“ Button geklickt um zum entsprechenden Formular zu gelangen. Auswahl der zu bearbei- tenden Freigabe Mit „Win-...
Seite 114
Das „Allowed for all“ Feld auswählen um Zugriff für alle zu gewähren Auf „Save“ klicken um Änderungen umzusetzen Um Rechte auf Benutzer- und Gruppenebene zu vergeben, die entsprechenden Benutzer Auswählen und auf den „<< Read Only“ Button klicken um ihnen reine Leserechte zu geben oder auf den „<<...
Um Rechte zu widerrufen, den entsprechenden Benutzer oder Gruppen auswählen und auf „Remove>>“ klicken. Benutzer und Gruppen auswählen denen Rechte entzogen werden sollen Auf „Remove>>“ klicken um Rechte zu entziehen Auf „Save“ klicken um Änderungen zu sichern Wie man auf eine Freigabe auf dem IB-NAS2001 vom Computer aus zugreift, ist in Punkt „Netzlaufwerke und Drucker verbinden“...
Seite 116
Auswählen von „Allow for all“ erlaubt NFS Zugriff von allen Rechnern Mit „Save“ die Änderun- gen speichern Um den NFS Zugriff für eine einzelne IP-Adresse oder ein ganzes Subnetz zu gewähren, die entsprechende Option auswählen, die IP-Adresse im zugehörigen Feld eingeben und auf „Add“...
Um die Rechte für IP-Adressen zu entziehen, die entsprechende IP-Adresse auswählen, auf „Remove“ klicken und mit „Save“ die Änderung speichern. Auswahl der IP-Adresse zum Entzug der Rechte Auf „Remove“ klicken um Rechte zu entziehen mit „Save“ die Änderun- gen speichern Wie man auf eine Freigabe auf dem IB-NAS2001 vom Computer aus zugreift, ist in Punkt „Netzlaufwerke und Drucker verbinden“...
Netzwerkeinstellungen Die Netzwerkeinstellungen, beschrieben im Punkt „Mit festen IP-Adressen konfiguriertes Netzwerk“ (Seite 15) können ebenso über die Managementoberfläche geändert werden. Außerdem kann hier der Netzwerkname des IB-NAS2001 geändert werden. Um das ent- sprechende Formular zu erreichen, wähle man: Control Panel System Network Setting Der Netzwerkname kann...
Neustart oder Auss chalten des IB-NAS2001 ferngesteu- In einigen Fällen mag es notwendig sein, das IB-NAS2001 neu zu starten oder auszu- schalten. Das kann auch über die Managementoberfläche geschehen. Um das entspre- chende Formular z u erreichen, wähle man: Co trol Panel System Turn off Server „Restart“...
Systeminformationen Um einige grundlegende Systeminformationen angezeigt zu bekommen, wähle man: Control Panel System Information Anzeige einiger System- informationen Festplattenbelegung (Disk Usage) Um einen schnellen Überblick über die Belegung der Festplatte zu bekommen wähle man: Control Panel System Disk Usage Um einen schnellen Überblick über die gesamte Belegung der Festplatte zu bekommen, wähle man „Summery“...
Für eine detaillierte Liste pro Benut zer, wähle man „Benutzer“ wie unten beschrieben: Durch Auswahl von „U- ser“ wird eine Liste nach Benutzern differenziert ausgegeben Netzwerk Dienste (Network Service) Das IB-NAS2001 bietet eine Reihe von Netzwerkdiensten an, so wie das gemeinsame Nutzen von Bildern, Musik und Filmen im lokalen Netzwerk oder DHCP.
DHCP Server Ein DHCP Server erlaubt es, Netzwerkgeräte zentral zu konfigurieren, die auf eine auto- matische Konfiguration eingestellt sind. Ein Netzwerkgerät, das auf automatische Konfi- guration eingestellt ist, versucht beim Starten mit einem DH CP Server in Verbindung treten und fragt diesen nach einer IP-Adresse. In einem Heim netzwerk wird dieser Die meist durch den Internetverbindungsrouter (z.
Manuelle DHCP Ko nfiguration Um die manuelle Konfiguration des DHCP Servers zu erreichen wähle man wie folgt: Control Panel Network Service DHCP Server Durch dieses Auswahlfeld wird der DHCP Server aktiviert oder deaktiviert Hier kann der DHCP Ser- ver konfiguriert werden Klicken auf „DHCP lease list“...
DHCP Einstellung Besch reibung DHCP IP Address Start Start des IP-Adressbereichs, aus dem die IP-Adressen die anfragenden Netzwerkgeräte vergeben werden. DHCP IP Address End Ende des IP-Adressbereichs. Maxim um Lease Time Maximaler Gültigkeitszeitraum für die vergebenen IP-Adressen. Netzwerkgeräte versuchen normalerweise nach Ablauf der halben Zeit, dieser Periode, die IP- Adresse erneut anzufragen.
Das Einschalten dieses Dienstes vereinfacht die Verwendung des IB-NAS2001 mit Mac Computern. Wenn Bonj our aktivi ert ist, dann kann der iTunes Support ebenfalls aktiviert werden. Der iTunes Sup port se ndet den Inhalt des „music“ Verzeichnisses in der „public“ Freigabe (Share) an alle iTunes Programme, die auf Computern im lokalen Netzwerk lau-...
Aktivieren / Deaktivieren von Twonky Media Um den Twonky Media Server zu aktivieren wählen sie: Control Panel Network Service Twonky Media Um den Twonky Media Server zu aktivieren wählen sie „Enable“ und … … klicken auf “save” um die Änderung umzuset- zen.
Gebrauch von Twonky Media Beim Start wird Twonky Media den gesamten Inhalt des IB-NAS2001 nach Musik, Bil- dern, und Filmen durchsuchen. Twonky Media ist so voreingestellt, dass er sofort funkti- oniert. Für Details über die Aktivi erung, die Lizenzierung und Bedienung von Twonky Media be- uchen sie bitte die Twonky Vision (Hersteller von Twonky Media) Homepage: http://www.twonkyvision.com Oder klicken sie auf die entsprechenden Symbole auf der Be...
Firmware-Upgrade Das IB-NAS2001 bietet die Möglichkeit ein Firmware-Upgrad e durchführen zu könne Das entsprechende Formular findet man unter: Control Panel Maintenance Firmware upgrade Der Upgrade-Prozess beginnt mit der Auswahl der entsprechenden Upgrade-Datei (Up- grade File) auf der lokalen Festplatte. Beim Klicken auf den „Browse“ Button öffnet sich ein Auswahldialog, mit dessen Hilfe die entsprechende Datei gewählt werden kann.
Nach dem Neustart ist eine erneute Anmeldung notwendig Sichern und Wiederherstellen der Einstellungen Das IB-NAS 2001 bietet eine Möglichkeit alle Einstellungen in einer Datei zu sichern und sie falls notwendig wiederherzustellen. Sichern der Einstellungen (Save configuration) Den Dialog zum Sichern de r Einstellungen findet man unter: Control Pane...
Wiederherstellen der Einstellungen (Restore Configuration) Das Formular zum Wiederherstellen der Einstellungen findet sich unter: Control Panel Maintenance Restore Configuration Um die Einstellungen wiederherzustellen auf „Browse“ klicken und mit dem sich öffnenden Dia- log die Konfigurationsda- tei auswählen Auf „Restore“ klicken um die Wiederherstellung zu starten.
USB-Sticks und USB-Festplatten Das IB-NAS2001 kann durch Anschluss von externen USB Massenspeiche rmedien erwei- tert werden, wie U SB-Sticks oder USB-Festplatten. Das IB-NAS2001 unterstützt derzeit bis zu zwei externe M assenspeichergeräte, da es zwei USB 2.0 Anschlüsse besitzt. Wenn einer diese r beiden Anschlüsse be reits durch einen Drucker belegt ist, wird nur noch ein eiterer USB Massenspeicher unterstützt.
Installation einer Applikation Die Installation einer Applikation ist denkbar einfach. Dazu muss lediglich die entspre- chende Installationsdatei in den Ordner „new_software“ im Ordner „applications“ in der Freigabe „public“ kopiert werden und das NAS neu gestartet werden. Die Installationsdatei in den Order „new_software“...
Netzlaufwerke und Drucke r verbinden Netzlaufwerke (Freigaben) in Windows verbinden Um auf IB-NAS2001 Freigaben unter Windows zugreife und Druckern zu können, wie unten beschrieben verfahren: it rechter Maustaste auf „ Arbeitsplatz“ klicken Auf „Explorer“ klicken „\\icybox“ in die Adress- zeile des Explorers ein- geben, wobei „icybox“...
Seite 134
Hier den angelegten Be- nutzernamen eingeben Hier das für den Benut- zernamen definierte Kennwort eingeben Auf „OK“ klicken Alle Freigaben, die das IB-NAS2000 anbietet werden hier angezeigt Mit der rechten Maustas- te auf diese Freigabe klicken, um sie zu ver- binden Auf „Netzlaufwerk ver- binden…“...
Seite 135
Den Laufwerks- buchstaben auswählen Zum Abschluss auf „Fer- tig stellen“ klicken Von nun an kann auf da Netzlaufwerk über den ausgewählten Lauf- werksbuchstaben zuge- griffen werden Downloaded from www.Manualslib.com manuals search engine...
Drucker in Windows verbinden Klicken sie auf „Start“ und wählen sie „Drucker und Faxgerä te“. In dem sich dann öf fnen- den Fenster klicken wählen sie anschließend „Drucker hinzufügen“. Auf „Weiter >“ klicken Wählen sie „Netzwerk- drucker oder Drucker, der an einen anderen Computer angeschlossen ist“...
Seite 137
Wählen sie „Verbindung mit folgendem Drucker herstelle n…“ Geben sie „\\icybox\lp“ ein, wobei icybox der Netzwerkname des NAS Klicken sie auf „Weiter >“ Auf „Ja“ klicken Auf „OK“ klicken Wählen sie einen Drucker aus dem Dialog oder… …oder wählen sie „Daten- träger…“...
Seite 138
Treffen sie eine Wahl Klicken sie auf „Weiter >“ Auf „Fertig stellen“ kli- cken um die Installation abzuschließen Nun ist der Drucker installiert und kann wie direkt an den Co mputer angeschlossen b nutzt werden. Wiederholen sie diese Prozedur auf allen Com putern in ihrem lokalen Netzwerk und sie können von allen Computern gleichzeitig auf dem Drucker drucken, der an das IB-NAS2001 angeschlossen ist.
Windows Freigaben auf MAC OS X verbinden Um Windows Freigaben auf MAC OX X zu verbinden, wie unten beschrieben verfahren: Den Finder öffnen “Network” auswählen Das IB-NAS2000 wird hier angezeigt Auf „ICYBOX“ doppelkli cken wobei „ICYBOX“ der Name des IB-NAS2000 Die Freigabe wählen, die man verbinden will Auf „OK“...
Die Freigabe ist nun über den Desktop zugänglich Drucker unter Mac OS X einbinden Öffnen Sie das „Drucker Dienstprogramm“ in dem sie im Menü „Gehe zu“ den Punkt „Dienstprogramme“ wählen und dann das „Drucker Dienstpr ogramm“ aufrufen: „Hinzufügen“ anklicken Downloaded from www.Manualslib.com manuals search engine...
Seite 141
Wählen sie „Windows Drucker“ Wählen sie den Namen der Arbeitsgruppe des IB-NAS2001, voreinge- stellt: „Workgroup“ Wählen sie „icybox“, wo- bei icybox der Name ih- res IB-NAS2001 ist Wählen sie das Drucker- model aus Auf „Hinzufügen“ klicken Geben sie den Benutzer- namen und das passende Kennwort eines Benut- zers an, den sie für das...
Windows Freigaben unter Linux mount Um Windows Freigaben unter Linux zu mounten, eine Shell öffnen und folgendes einge- (<IP Address>= IP-Adresse des IB-NAS2001, <share>=Windows Freigabe des IB- NAS2001, <user>= Benutzername, <pass>= Passwort, <m ountpoint>= Pfad des Mount-Verzeichnisses): mount –t smbfs //<IP Address>/<share>...
Lizenzbedingungen für Vergleichstests RaidSonic IB-NAS1000, IB-NAS4220-B, IB-NAS2000 Firm- ware ie sind berechtigt, interne Vergleichtests mit der Fir mware der Modelle IB-NAS1000, IB- NAS4220-B und IB-NAS2000 durchzuführen. Sie sind berechtigt, die Ergebnisse von Vergleichstests mit d er Firmware der Modelle IB-NAS1000, IB-NAS4220-B und IB- NAS2000 offen zu legen, vorausgesetzt, Sie halten die folgenden Bestimmungen ein: (1) Ihre Offenlegung muss alle für die Replikation der Tests notwe ndigen Informationen ent-...
