Technical specifications

General

Minimum System Requirements: PC with sound card, or any stand-alone audio source with
line-level output.
Cables supplied: IEC mains cable, 3.5 mm stereo jack to phono and loudspeaker cables.
Approvals: CE marked. Compliant with the EMC and Low Voltage Directives (89/336/EEC and
73/23/EEC).
Dimensions:
Technical support: Technical hotline and Internet web site.
Warranty: Two years.

Loudspeakers

Subwoofer
Wood construction MDF cabinet, containing magnetically shielded bass drive unit.
Low frequency drive unit: Audax 6.5" cone (35 Hz to 130 Hz)
Satellites
Wood construction MDF cabinets, each with mid-frequency (bass/mid) drive unit and separate
high-frequency drive unit (tweeter), both magnetically shielded.
Bass/mid frequency drive unit: Audax 4" cone (130 Hz to 3.8 kHz)
High frequency drive unit: Audax 10 mm polymer dome (3.8 kHz to 20 kHz)
26
Downloaded from www.Manualslib.com
Satellites: 130 mm (W - front) x 80 mm (W - back) x 200 mm (H) x 150 mm (D)
Subwoofer: 235 mm (W) x 420 mm (H) x 370 mm (D)
Amplifier: 204 mm (W) x 86 mm (H) x 340 mm (D)
