*RB37* model only
(1)
(2) (3)
(5)
RB3000J_User-servicing-manual.indb 7
Cap space Door
Cap space
Door
(4)
English
2. Disassemble the Cap space Door.
3. Remove the Cover Hinge to push a hook
like below Pictures.
• Insert a flat-head screwdriver and put it
back as shown in Figure #1.
• As shown in Figure #2, Lever up the cover
and push a hook as shown in Figure #3.
(Take care not to damage the Cover Hinge
Wire by pushing it too hard)
• Disassemble it by pushing the A in Figure
#4 by hand as Figure #5.
4. Disconnect the wiring connector for the
fridge door. (Only on models with external
display).
5. Remove the screws. (Be careful not to drop
the door when you disassemble it.)
