Reversing the door
1Door_RR7000_User-servicing-manual.indb 6
1. Use a flat-head screwdriver to insert in the
holes one after another on the top of the
door to remove the top frame cover.
NOTE
Start with the hole farthest from the hinge.
2. Pull out the left side of the hinge cover
to remove, and then slightly lift up the
bottom to pull out.
CAUTION
When removing the hinge cover, use caution
not to damage the connectors and wires on or
around the fridge door.
NOTE
Keep the hinge cover in a safe place. It is
necessary when you return the door to the
initial position (before reversing the door).
3. Disconnect the connectors on or around
the fridge door. Loosen the screws from
the top hinge to remove.
CAUTION
To prevent the fridge door from falling,
make sure to hold the fridge door tight while
removing the top hinge.
