Installation
Switching On /Off
Switching on:
To start the appliance squeeze on the ON / OFF switch
(3) and then keep it pressed down. The LED working
light (7) comes on with a slightly or fully pressed ON /
OFF switch (3) and illuminates the working area in
poor lighting conditions.
Switching off:
To stop the appliance, release the ON / OFF switch (3).
Adjusting the speed
The ON / OFF switch (3) has a variable speed control
device. Slight pressure on the ON / OFF switch (3)
will cause the rotation speed to slow down. With in-
creased pressure, the rotational speed will increase.
Note: The integrated engine brake means that the
device will come to a fast standstill.
Switching direction of rotation
To switch the direction of rotation, push the direction
of rotation switch (2) to either the right or to the left.
Tips and Tricks
Before you use the appliance, check to see that the
screw or drill bit is properly fitted, i.e. located centrally
in the chuck. Screw bits are designated with their di-
mensions and their shape. If you are unsure, always
try the particular screw bit out to see whether it sits in
the screw head without any free play.
Torque:
Smaller screws and bits in particular can be easily
damaged if you adjust the appliance with too high a
torque and/or rotation speed.
Hard screwdriving conditions (into metal):
Particularly high torques can occur, for example with
metal screws tightened by socket tool bits. Select a
lower rotation speed.
Soft screwdriving conditions (e.g. into soft
wood):
You should also select a low speed in order not to
damage the wood workpiece surface through contact
with the metal screw head.
Use a countersinker.
When drilling into wood, metal and other materials, take
note of the following advice: With small diameter drill
bits use a high drill speed. For large diameter drill bits,
use a low drill speed. For hard materials, select a low
drill speed. For soft materials, select a high drill speed.
Secure or fix down the workpiece (if possible) in a
clamp or vice.
22 | GB
 www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58
Mark the intended position of the hole with a centre
punch or a nail and select a low drill speed for drilling.
Take the rotating drill bit out of the hole frequently so
that swarf or drill dust can be re-moved and the hole
and tool is ventilated.
Drilling in metal:
Use a metal drill bit (HSS). For the best results, you
should cool the bit with oil.
Metal drill bits can also be used to drill into plastic.
Drilling in stone:
Use a circular shafted masonry drill bit with a hard-
ened metal tip.
Drilling in wood:
Normally you should use a wood drill with a centring
point. For deep holes, use an auger type bit. For large
diameter holes, use a forstner bit. You can screw small
screws into soft wood without the need for pre-drilling.

12. Cleaning

Danger!
Always pull out the battery pack before starting any
cleaning work.
• Keep all safety devices, air vents and the motor
housing free of dirt and dust as far as possible.
Wipe the equipment with a clean cloth or blow it
with compressed air at low pressure.
• We recommend that you clean the device immedi-
ately each time you have finished using it.
• Clean the equipment regularly with a moist cloth
and some soft soap. Do not use cleaning agents
or solvents; these could attack the plastic parts of
the equipment. Ensure that no water can seep into
the device. The ingress of water into an electric tool
increases the risk of an electric shock.

13. Storage

Store the device and its accessories in a dark, dry
and frost-proof place that is inaccessible to children.
The optimum storage temperature is between 5 and
30˚C. Store the electrical tool in its original packag-
ing. Cover the electrical tool in order to protect it from
dust and moisture. Store the operating manual with
the electrical tool.

14. Maintenance

There are no parts inside the equipment which re-
quire additional maintenance.
