9. Operation

a) Getting started
1. Flip the display panel open or press the power
2. Position the lens over the object and adjust the LED brightness using the brighness dial.
3. Adjust the focus dial to bring the image into sharp focus.
4. Rotate the polarizer lens ring to reduce glare.
It may take a few moments for the white balance to auto adjust and bring the image into focus. If there is
too much glare from the object, consider lowering the LED brightness (or turning it off completely).

b) High and low magnification

High magnification
1
• Turn the focus dial all the way to the left "+", then slowly dial back until the image comes into focus.
• The focal length will be short, so you may need to position the lens much closer to the object.
Low magnification
2
• Turn the focus dial all the way to the right "-", then slowly dial back until the image comes into focus.

c) Digital zoom

1. Use the focus ring to bring the object into focus on the LCD display.
to zoom in + or out -.
2. Press

d) Select photo or video mode

1. Press to switch between photo and video modes:
- Photo mode: shows on the display.
- Video mode:
2. Press the capture button
A blinking red
shows on the display.
to take photo or start/stop recording.
icon indicates recording is in progress.
button to turn the microscope ON / OFF.
27
