7. Technical data and performance characteristics
Suitable for LoRaWAN® IoT solutions from ZENNER and network operation of Minol ZENNER Connect
■
Bidirectional LoRaWAN® radio communication
■
Encrypted end-to-end data transmission (AES 128)
■
No storage of meter readings on the gateway
■
Plug & Play - Simple integration through pre-configured software
■
Compatible with the Gateway Management System (GMS) from ZENNER (remote configuration)
■
Security patches and software updates are distributed in an automated manner
■
Use in Europe, USA and China possible (country frequencies must be observed)
■
LoRaWAN®-Gateway modules according to reference architecture 1.5
■
Automatic change from cellular network to Ethernet backhaul (if available)
■
Technical data
Cellular network
Ethernet
# LoRa channel
TX power
Frequency
Power supply
Antennas
Protection class
Housing
Operating temperature
Storage temperature
Installation
Maintenance
Standards
Weight
* ZENNER IoT Gateways (Indoor and Outdoor) are only compatible as standard with the ZENNER system landscape or ZENNER
LoRa network server (LNS) by means of Plug'n'Play. The gateways are automatically detected in the backend and can subse-
quently be monitored and configured by the integrated Gateway Management System (GMS). Software updates and security
patches are also distributed in an automated manner. Network operation is performed by Minol ZENNER Connect GmbH.
Mini SIM – 2G, 3G (UMTS), 4G (LTE) – external LTE antenna
RJ45 – priority over cellular network
16 channels - two external antennas
max. 27 dBm (500 mW) conducted
EU-868
Power over Ethernet (PoE)
external: 2 x LoRa, 1 x cellular network (antennas incl. mounting bracket included in scope
of delivery)
IP67
Aluminium, coated
0 °C to +50 °C
- 40 °C to + 80 °C
Wall, pole (bracket incl. grounding cable included in scope of delivery, galvanized steel)
Remote firmware upgrades
EN 301 489-3, EN 300 220-2
approx. 4.1 kg
