CHARACTERISTICS

Ref. Q.ty Product Components
1 1
2 1
2.1 1
2.2 1
9 1
14.1 2
15 1
Ref. Q.ty Installation Components
7.2.1 2
7.3 1
11 6
12a 6
12c 6
Q.ty Documentation
1
EN
Downloaded from www.Manualslib.com
Components
Hood Body, complete with: Controls, Light, Blower,
Filters
Telescopic Chimney comprising:
Upper Section
Lower Section
Reducer Flange ø 150-120 mm
Air Outlet Connection Extension
Air Outlet Connection
Upper Chimney Section Fixing Brackets
Air Outlet Connection Support
Wall Plugs
Screws 4,2 x 44,4
Screws 2,9 x 9,5
Instruction Manual
manuals search engine
Dimensions
9
2.1
2
2.2
1
15
14.1
7.3
12a 7.2.1
11
12c
11
12a
8 8
