NiCd-BATTERIES
NiCd CHARGE
Push the button "BATT TYPE" until the display shows "NiCd". Now use the "INC" or "DEC" button to get to "CHARGE" and then push "ENTER"
to confirm. After your confirmation the display will change to the capacity "CAP". Now please set the capacity of your battery with the
buttons "INC" or "DEC" from 100 mAh to 5000 mAh and confirm with "ENTER". The display changes to the charge current "C" which can be
set with the "INC" or "DEC" buttons from 0.1 A to 5.0 A. The parameters shown on the display are set and stop flashing if no push button is
pressed for 3 seconds. To start charging, now push the "ENTER / START / STOP" button for 2 seconds. The display shows "BATTERY CHECK
WAIT PLEASE". After a short check of all parameters the display shows the battery type "NC", the charge mode "CHG", the charge current e.g.:
"+1.50A" and the actual measured battery voltage "V". The clock starts running in seconds and the display shows also the charged capacity.
When the charging is finished you will get an audible signal. The display shows the trickle charge current and the capacity charged into the battery.
Adjustments and the associated display can be seen in the following chart:
NiCd CHARGE
CAP=3000mAh
NiCd CHARGE
CAP=3000mAh
NiCd CHARGE
C=3.0A
Battery check
Wait please...
CHG 0:00 00000
NC + 3.00A 4.65V
NiMH-BATTERIES
The menu setup of NiMH is equivalent to NiCd.
