INDEX

Function
AC Input
DC Input
Charge sockets
Charge sockets
Charge current
Charge end voltage

OPERATION

xBase Deluxe
Connect the
the right polarity: red = + plus, black = - minus. When the charger is connected in the right way you will get an audible signal and the display shows the charge
menu. If the display doesn't show anything the power supply is not connected correctly. If the input voltage is <11V or > 15V the display shows "INPUT VOLTAGE".
Now connect the battery pack with a suitable cable to the charger (Banana sockets). Please take care to use the right polarity: red = + plus, black
= - minus. If the polarity of the battery is wrong the display shows "WRONG POLARITY". If there is no battery connected and the Button "START" is
pushed the display shows "NO BATTERY". For further adjustments please follow the attached Menu Navigation.
MENU
After you have connected the
pushing the button "BATT TYPE" once the displayed battery type will start flashing. By pushing "BATT TYPE" again the display changes between the
battery types (NI=NiCd; NH=NiMH; LI=Li-Ion; LP=Li-Po; PB=Lead Acid). Flashing of the battery type display will stop when pushing another button or
after a short time if no button is pushed.
The last used configuration will be saved.
