DISPLAY

2 rows with 16 digits
CHG
NC+1.40A 9.524V
1
1. Shows the different battery type and the function
NiCd = NiCd battery
NiMH = NiMH battery
LiIo = LiIon battery
LiPo = LiPo battery
PB = Lead Acid battery
CHG = Charge
2. Shows the battery type (Chemistry) during charge / Capacity / charge current
NC = NiCd battery
NH = NiMH battery
LI = LiIon battery
LP = LiPo battery
PB = Lead Acid battery
CAP = capacity (at NiCd or NiMH)
C = capacity (at LiIon, LiPo or Lead Acid)
C = charge current
3. Shows the adjusted charge current
+1.40 = charge current of 1.40 A
4. Shows the expired time of the adjusted charge mode, Format in MMM:SS (M= Minutes S= Seconds)
5. Shows the actual measured battery voltage in V
6. Shows the charged capacity in mAh
