CMC TRISKELION Anleitung Seite 8

INSTRUCTIONS FOR USE
TRISKELION AS A HIGH ANCHOR
Example: With a self-retracting lifeline
•
Attach the self-retracting lifeline to an anchor point on the
Triskelion head (Figure 7 and 8).
•
Keep the load within the Triskelion legs (Figure 7 and 8).
•
Do not operate a load outside of the Triskelion legs
(Figure 9).
WARNING
•
Operating outside of the Triskelion legs can create
a sideways swing and topple the tripod. Keep the
load within the legs.
•
For safety, verify there is adequate distance and
clear space below the area of operation so that in
the event of a fall, the User will not come in contact
with the ground or other obstacles.
8
USER MANUAL
TRISKELION
Figure 7
Figure 8
Figure 9
