GENERAL SETUP PAGE
PLAYING MP3/DIVX/PICTURE FILES
DivX®, DivX
TM
Certified, and associated logos are trademarks of DivX, Inc. and used
under license.
This unit can play MP3, DivX and Picture files recorded on CD-R/CD-RW discs, USB
flash drive and SD/MMC card.
1. Insert a disc.
2. The content of disc will be displayed on screen.
3. Press ◄, ►, ▲,▼ button to view and select the file that you want to play, then press
ENTER button to confirm the selected file and start playback.
4. Press
button to stop playback.
Note: For playing files on USB flash drive or SD/MMC card, you should plug in the USB
TV DISPLAY
flash drive or SD/MMC card when the unit is in OFF mode. Turn ON the unit and press
4:3 PANSCAN
SOURCE button to select USB or SD/MMC mode.
• When wide-screen video is played, this mode clips the right and left sides of the image
so that it can be viewed on a conventional screen.
Notes:
• Some wide-screen DVDs that do not permit Pan Scan mode playback are
• Avoid long file names! It is suggested to name the file names using 11 or fewer
automatically played in letterbox mode (black bands top and bottom).
characters.
• The total number of files on the disc should not exceed 254.
4:3 LETTERBOX
• The maximum number of directories should not exceed 32.
• When wide-screen video is played in this mode on a conventional screen, black bands
• The maximum depth level of directories should not exceed 4.
appear at the top and bottom of the screen.
Supporting format:
16:9 (Wide screen)
MP3:32kbps-320kbps
• This is the correct mode for playing wide-screen videos on a wide-screen TV.
JPEG:up to 8000X6000 pixels and file size less than 8MB
MPEG :MPEG-1 (ISO/IEC 11172-2), MPEG-2 (ISO/IEC 13818-2), MPEG-4 ASP(DivX)
WIDE SQUEEZE
AVI:up to 720X576
The wide-screen image will be displayed in full screen in its native aspect ratio and so
VOB(DVD):720 x 480i, 720 x 576i, 720 x 480p, 720 x 576p
does the 4:3 image but with black borders on the left and the right side.
DivX:3.11 / 4.0 /5.0
Notes:
• The visible picture size is preset on the DVD disc. Therefore the playback picture of
SETUP MENU
some DVD discs may not conform to the picture size you select.
• When you play DVD discs recorded in the 4:3 aspect ratio, the playback picture
Navigating the setup menu
will always appears in the 4:3 aspect ratio regardless of the TV shape setting in the
1. Press SETUP to display the setup main menu.
function setup menu.
2. Press ◄, ► to select a menu icon.
3. Press ▲ , ▼ to select one of the available options under a menu icon.
ANGLE MARK
4. Press ► to access the submenu and ▲ ,▼ to select an option.
ON: To show angle mark when a disc with multiple camera angles is playing. You can
5. Press ENTER to confirm your selection.
view different camera angles of a DVD disc by pressing ANGLE button on remote
control.
6. Press◄ to return to a previous menu.
OFF: To hide angle mark.
7. Press SETUP to exit from the setup menu.
NOTE: This function is only available for discs encoded with multiple camera angles.
OSD LANGUAGE
• To select the language of unit's menus.
GB - 12
IMPORTANT SAFETY PRECAUTIONS
• Ensure a minimum distance of 5cm around the apparatus for sufficient ventilation.
• Do not place objects filled with liquids, such as vases, on the apparatus.
• The marking plate is located on the bottom of unit.
NEVER fit make shift stands or legs with woodscrews. Use only approved supports and
fasteners specially designed for the equipment.
• Attention should be drawn to the environmental aspects of battery disposal.
NEVER let anyone, especially children, push objects into holes, ventilation slots or any
• Do not throw batteries in fire!
• Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
other opening; this could result in fatal electric shock!
ALWAYS disconnect the AC adaptor when you are not going to use the unit for a long
• Excessive sound pressure from earphones and headphones can cause hearing loss.
period of time.
• Under the influence of electrical fast transient or/and electrostatic phenomenon, the
product may malfunction and require user to power reset.
ENSURE that all electrical connections (including the mains plug, extension leads and
interconnections between pieces of equipment) are properly made in accordance with
the instructions given. Switch off the main supply when making or changing connections.
MAINTENANCE
CONSULT your dealer if you are ever in doubt about the installation, operation or safety
of your equipment.
Cleaning
DON'T continue to operate the equipment if it is damaged in any way or if it does not
Be sure to turn the unit off and disconnect the AC adaptor before maintaining the
function normally. Disconnect the AC adaptor and consult your dealer.
DON'T leave equipment switched on when it is unattended unless it is part of it's normal
unit.
• Use a soft, dry, clean cloth. Regularly dust the vents at the back or sides.
function to operate in your absence, for example a video cassette recorder with timed
• Using solvents, abrasive or alcohol-based products risks damaging the appliance.
recording facility.
LISTEN to headphones at moderate volume levels; high volume levels can permanently
• If an object or liquid enters inside the appliance, unplug it immediately and have it
checked by an authorized engineer.
damage your hearing.
WARNING:
Note on disc
• Do not use irregular shape CDs (example: heart-shaped, octagonal ones). It may
• AC adaptor is used as the disconnect device. It shall remain readily operable and
result in malfunctions.
should not be obstructed during intended use. To be completely disconnected the
apparatus from supply mains, the AC adaptor of the apparatus shall be disconnected
• Do not place more than one disc in the disc compartment.
• Do not try to open the disc compartment during playing.
from the mains socket outlet completely.
• Never use an AC adaptor that is damaged, route power lead in a safe manner and
• Do not touch the lens. Doing so may cause malfunction.
make sure it is not subjected to trapping or pinching. If the power lead is damaged
• If there is a scratch, dirt or fingerprints on the disc, it may cause tracking error. Before
playing, clean the disc with a cleaning cloth. Wipe the disc from the center out. Don't
refer to a qualified service agent.
• Place the unit on a flat and even surface.
store discs in places with high temperatures or high humidity, they can become
• Do not restrict the air flow of the unit by placing it in a place with poor air flow, by
warped. After playing, store the disc in its case.
covering it with a cloth, or by placing it on carpeting.
• To avoid magnetized, do not place the unit near speaker or magnet.
Important Note
• Do not use this unit in direct sunlight or leave the unit in a closed automobile (or yacht,
• Before transporting the unit, remove the disc from the disc compartment.
etc) where it would be exposed to high temperatures above 40°C.
• It also should not be placed in temperatures less than 5°C or greater than 35°C.
• No naked flame sources such as lighted candles should be placed on the AC adaptor
and main unit.
• Do not use the unit immediately after transportation from a cold place to a warm place,
condensation problem may result.
• The ventilation should not be impeded by covering the ventilation openings with items
such as newspapers, table-cloths, curtains, etc.
• No naked flame sources, such as lighted candles, should be placed on the apparatus.
• The use of apparatus in moderate climates.
• The apparatus should not be exposed to dripping or splashing.
GB - 18
DVP-3836 IB MUSE 001 REV0- GB.indd 2
CLOSED CAPTIONS
Some discs have closed captions.
ON: Show the closed captions.
OFF: Hide the closed captions.
SCREEN SAVER
To set screen saver ON or OFF.
AUTO STANDBY
This function allows you to select the standby setting:
OFF: The unit will not switch to standby mode.
3 HOURS: If no button is pressed within 3 hours, the unit will switch to standby mode
automatically.
4 HOURS: If no button is pressed within 4 hours, the unit will switch to standby mode
automatically.
AUDIO SETUP PAGE
DOWNMIX
LT/RT: left and right soundtrack audio output
STEREO: Stereo audio signal output
DOLBY DIGITAL
DUAL MONO
To select STEREO, L-MONO (left mono), R-MONO (right mono) and MIX- MONO for
Dolby Digital output.
DYNAMIC
• To control the different sound levels via dynamic compression. It improves the quality
of the sound track at a low volume, and quiets the loudest sounds.
• This function is available only on DVD discs recorded in Dolby Digital.
GB - 13
GB - 14
PLACEMENT
Mounting bracket
Mounting in the Vehicle
Use the supplied car mounting brackets to install units on the back of the vehicle's
headrests.
1. Remove the 4 screws on the headrest bracket. Fix the headrest bracket into the
steel pipes of the vehicle's headrest using these screws.
GB - 19
GB - 20
VIDEO SETUP PAGE
AUDIO
• To select the dialog language.
• If the selected language is not available on the disc, the disc's language will be used
instead.
• To change the dialog language during playback, press AUDIO on the remote control.
SUBTITLE
• To select the language of the DVD subtitles. Select "OFF" to turn off the subtitles.
• If the selected language is not available on the disc, the disc's language will be used
instead.
• To change the subtitle language during playback, press SUBTITLE on the remote
control.
BRIGHTNESS: To adjust the video brightness level on a scale of -16 to +16.
DISC MENU (menu language)
CONTRAST: To adjust the video contrast level on a scale of -16 to +16.
• To select the language of the DVD menus.
HUE: To adjust the color hue level on a scale of -9 to +9.
• If the selected language is not available on the disc, the disc's language will be used
SATURATION: To adjust the color saturation level on a scale of -9 to +9.
instead.
DivX VOD
PARENTAL
• Some DivX Video-On-Demand files required registration code, please get the code of
Some DVD discs are equipped with a password function and are rated according to
your DVD player.
their content. The contents allowed by parental lock level and the way a DVD disc is
• Registration code is for DivX Video-On-Demand only, do not apply this code for
controlled may vary from disc to disc. For example, if the disc allows, you could lock-
another applications or websites.
out violent scenes unsuitable for children or you could lock out playback of the disc
altogether.
PERFERENCE PAGE
You cannot play DVD discs rated higher than the level you selected unless you cancel
Note: The Preferences Setup menu is only available at stop mode.
the parental lock function.
The parental lock levels are equivalent to the following ratings.
Level 1 : Kid Safe
Level 2 : G
Level 3 : PG
Level 4 : PG-13
Level 5 : PG-R
Level 6 : R
Level 7 : NC17
Level 8 : Adult
MEPG4 SUBTITLE
TV TYPE
If your DivX video file includes subtitle file, use this to select your preferred subtitle
• To select your TV system among PAL, AUTO or NTSC.
language.
DEFAULT
Pressing ENTER with this function selected resets all settings to their initial factory
state, except for parental level and password.
GB - 15
2. Fix the back holder and connecting shaft through the joint rotation fastening knob.
5. Connect the 12V car plug as shown.
CAUTION: Using other car plugs could damage the unit.
3. Combine the holder into the headrest bracket.
4. Fix the unit to the back holder using the knob screws.
SAFETY WARNING!
• On no account should this unit be used by the driver of a moving motor vehicle, or left
unsecured in the vehicle whilst driving.
• If this unit is being used by a passenger in your vehicle, be sure that it is secured or
held safely, and does not obstruct any safety device (i.e. airbag, seat belt etc.) that is fitted.
• All passengers should wear seat belts when using this unit in a moving vehicle.
Caution!
• If in doubt, please contact your vehicle manufacturer for further advice.
- Make sure the screws are properly locked to avoid accidental loosening.
• Using other car power adaptors could damage the unit.
- Always remember to lock the holder to ensure the safety of your passengers.
- Do not install when car travels.
GB - 21
PASSWORD SETUP PAGE
PASSWORD MODE
To turn the password mode ON/OFF.
PASSWORD
This option allows you to set or change the password.
Use
,
button to select "PASSWORD", press
button to highlight "CHANGE", then
press the ENTER button. Press the number buttons to input your 4-digit password until
to "OK" (If the password has not been set yet after you purchase this unit, it is "1369").
SAFETY INSTRUCTION
ATTENTION: To reduce the risk of electric shock, do not
remove the cover or back. There are no user serviceable parts
inside the unit. Refer all servicing to qualified personnel.
The lightning flash with arrowhead symbol within the triangle is a warning sign
alerting the user of "dangerous voltage" inside the unit.
The exclamation point within the triangle is a warning sign alerting the user of
important instructions accompanying the product.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
CAUTION: Invisible laser radiation when open and interlocks defeated. Avoid exposure
to beam. Class 1 laser product.
GB - 16
GB - 17
TROUBLE SHOOTING
No power.
• Ensure the AC adaptor is connected.
• Make sure that the unit is turned on.
The remote control does not function.
• Make sure the infrared remote sensor is not blocked.
• Point the remote directly at the infrared remote sensor on the unit.
• Replace the battery in the remote with a new one.
Very little or no sound is coming from a DVD.
• Make sure that the unit is turned ON.
• Make sure the unit is not paused. Press
.
• Make sure the unit is not in fast-forward or fast-reverse mode. Press
• Make sure that the connections are correct.
• Make sure the MUTE function is not on.
The player does not start playback
• Insert the disc with the printed side facing front.
• Check that the disc can actually be played by this device.
• Check that the disc's regional code matches the player's regional code. This player's
regional code is 2.
• Clean the disc.
The picture is not clear.
• The DVD is dirty. Gently clean the disc.
• The disc is scratched.
• Please adjust the LCD's brightness and contrast in SETUP MENU.
Forget Password
If you forget your own password, enter "1369" to reset.
Specifications and appearance are subject to change without notice.
10, Rue de la Mission, 25480 Ecole Valentin, France
GB - 22
GB - 23
.
NEW ONE S.A.S
M-1095 CVB/IB/V0
2016/9/13 8:46:41
Werbung
