Schreder TFLEX Installationsanleitung Seite 6

e
2
E
SUSPENDED SWIVELING FIXATION, ADJUSTABLE
C
1228,5 mm
A1
48.36 in
839,5 mm
A2
33.05 in
450,5 mm
A3
17.73 in
01-55-960 | DOC-0018753 rev B | 10-2020
A2
A3
440 mm
B
17.32 in
2xM8
A1
B
166,5 mm
C
6.55 in
www.schreder.com
+1.0Nm
20 Nm
-0.0Nm
8 kg
1OB
17.6 lb
15 kg
2OB
kg/lb
33.06lb
±1 kg
23 kg
3OB
50.70 lb
Ansi3G
6/15
