Schreder TFLEX Installationsanleitung Seite 3

C
C
Ø 9 mm
C
A1
A2
A3
01-55-960 | DOC-0018753 rev B | 10-2020
FIXED BRACKETS
A2
A3
1177 mm
46.33 in
788 mm 440 mm
B
31.02 in 17.32 in
399 mm
15.70 in
22.5
R4.5
24
180 mm
A1
B
116.5 mm
C
4.56 in
www.schreder.com
Ansi3G
440
8 kg
1OB
17.6 lb
15 kg
2OB
kg/lb
33.06 lb
23 kg
3OB
50.70 lb
22.5
15
3/15
