Schreder TFLEX Installationsanleitung Seite 4

D
SUSPENDED SWIVELING FIXATION, PULL OUT
C
1228,5 mm
A1
48.36 in
839,5 mm
A2
33.05 in
450,5 mm
A3
17.73 in
1
01-55-960 | DOC-0018753 rev B | 10-2020
A2
A3
440 mm
B
17.32 in
1
2
A1
B
166,5 mm
C
6.55 in
22.5
R4.5
24
www.schreder.com
Ansi3G
8 kg
1OB
17.6 lb
15 kg
2OB
kg/lb
33.06 lb
±1 kg
23 kg
3OB
50.70lb
1
2
440
IK09
22.5
15
4/15
