Orienting the Interactive Whiteboard (Windows 7)

This function serves to tune the whiteboard for the image to be projected onto it.
1. Using the mouse left button, click on the Oliboard Driver icon
bar at the bottom. Select "Orientation" in the popup menu, then select "IR
Touch Oliboard Touch".
2. Select the calibration function in the displayed window.
3. With the finger or the whiteboard pen, click on the mid-point of the cross "+" on
the whiteboard. Repeat this same operation for all the other orientation points,
being careful to canter well the mid-point of the flashing cross with the electronic
pen.
4. Save orientation.
INSTRUCTION: Select "orientation" the first time you install the Oliboard
Driver or if the position of the projector or the Interactive
Whiteboard changes, or if the display mode changes (e.g. the
image size or resolution).
