Allgemeine Informationen
1 2 3
Installation
Install a line circuit breaker into the mains cable
between the inverter and the feed meter to
secure it against overcurrent.
In countries in which a second PE connection
is prescribed, connect this at the marked place
on the housing.
Connecting AC-side
Connect the wires of the mains cable to the
AC terminal in accordance with the labelling.
For connection with a computer or with a
computer network. Connect several inverters
to a network for data retrieval.
1
2
3
4
© 2019 KOSTAL Solar Electric GmbH
4 5 6 7 8 9 10 11
DANGER
Risk of death due to electrical
shock and discharge!
De-energise the device,
secure it against being
restarted and wait five
minutes so that the capaci-
tors can discharge.
IMPORTANT NOTE
To connect the AC cables,
the inverter is equipped with
spring-loaded terminal strips.
INFO
For connection with a
computer, an Ethernet cable
of category 6 is to be used.
