Connection of one computer to multiple monitors
(optional, more DockingStations are necessary)
1. Connect a compatible computer to the powered DockingStation
(Dock 1)as shown above.
2. Connect a USB 3.0 Type-A port of Dock 1 to the USB Type-B host
interface of a second DockingStation (Dock 2, not included) via a
supported USB 3.0 cable (not included).
3. Connect monitors to both docks via standard DisplayPort
(not included).
Note: The device can work with any compatible DisplayLink DockingStation to set
up similar connections as shown in the drawing below.
A third DockingStation in a row is also supported (up to six monitors then), but keep
the lower performance in mind due to the USB 3.0 bandwidth limitation.
Dock1
Dock2
Please set up your display settings according to your operating system and require-
ments. For detailed information of your operating system, consult the respective
operation manual and description of your operating system.
