• Beim Wechsel vom ersten zum zweiten Akku muss eine Fahrpause von mindestens 10 Minuten
eingehalten werden. Beim darauf folgenden Wechsel muss unbedingt eine Ruhepause von mindes-
tens 20 Minuten eingehalten werden.
• Permanenten Motoreinsatz vermeiden.
• Schaltet sich das Fahrzeug mehrmals kurz hintereinander von selbst ab, ist der Akku leer. Bitte la-
den Sie den Akku.
• Zum Ausschalten nach der Fahrt umgekehrte Reihenfolge einhalten.
• Nach der Fahrt den Akku herausnehmen bzw. abklemmen. Laden Sie den Akku unbedingt nach
Gebrauch wieder auf, um eine sog. Tiefenentladung des Akkus zu vermeiden. Der Akku muss nach
Gebrauch mind. 20 Minuten abkühlen, bevor er wieder vollständig geladen werden darf.
• Lagern Sie den Akku immer außerhalb des Fahrzeuges.
• Das Carrera RC-Fahrzeug nach der Fahrt säubern.
Controller-Funktionen
Wenn der Controller eingeschaltet ist leuchtet die rote LED-Lampe am Controller.
11
Steuerung Digital Proportional
12
Gashebel nach hinten: stufenlos vorwärts
Gashebel nach vorne: Bremsen bzw. stufenlos rückwärts
Steuerrad im Uhrzeigersinn drehen: stufenlos rechts
Steuerrad gegen Uhrzeigersinn drehen: stufenlos links
Bitte beachten Sie, dass die Rückwärtsgeschwindigkeit aus Sicherheitsgründen um ca. 40% reduziert ist.
Steering-TRIMM – Lenkfeinjustierung
13
Sollte das Fahrzeug nicht geradeaus fahren, können Sie hier Ihr Fahrzeug fein justieren.
Dank 2,4 GHz Technologie können bis zu 16 Fahrzeuge gemeinsam auf einer Rennstrecke gefahren
14
werden. Dies ist ganz ohne Frequenz-Abstimmung unter den Rennfahrern möglich.
Problemlösungen
Problem: Modell fährt nicht.
Ursache: Schalter am Controller oder/und Modell steht/ stehen auf „OFF".
Lösung: Einschalten.
Ursache: Schwacher oder gar kein Akku im Modell.
Lösung: Geladenen Akku einlegen.
Ursache: Das Auto ist an einem Hindernis stehen geblieben.
Lösung: Der Überspannungsschutz hat das Auto abgeschaltet. ON/OFF Schalter am Fahrzeug einmal auf
OFF, dann wieder auf ON schalten und auf einer freien Fläche platzieren.
Ursache: Schwacher Akku/Batterie im Controller oder Modell.
Lösung: Geladenen Akku oder Batterie einlegen.
Ursache: Das Fahrzeug ist sehr warm.
Lösung: Fahrzeug und Controller ausschalten und das Fahrzeug etwa 30 Minuten abkühlen lassen.
Ursache: Der Überhitzungsschutz hat das Auto wegen zu starker Erwärmung angehalten.
Lösung: Den Empfänger ausschalten Das RC-Fahrzeug etwa 30 Minuten abkühlen lassen.
Problem: Keine Kontrolle.
Ursache: Fahrzeug setzt sich ungewollt in Bewegung.
Lösung: Stellen Sie wie unter „Einsetzen des Akkus"
Modell und Controller her.
Irrtum und Änderungen vorbehalten · Farben / endgültiges Design – Änderungen vorbehalten
Technische und designbedingte Änderungen vorbehalten · Piktogramme = Symbolfotos
Dear customer
Congratulations on purchasing a Carrera RC model car, manufactured in accordance with the latest technology. As
it is our constant endeavour to develop and improve our products, we reserve the right to make modifications, either
of a technical nature or with respect to features, materials, and design, at any time, and without prior notice. For this
reason, no claims will be accepted for any slight deviations in your product from the data and illustrations contained
in these instructions. These operating and assembly instructions are an integral part of the product. Non-observance
of these operating instructions and the safety instructions they contain will render the guarantee null and void. These
instructions are to be kept for future reference and in the event that the product is passed on to a third party.
For the latest version of these operating instructions and information on replacement and spare parts
avail able, please visit carrera-rc.com in the service area.
Guarantee conditions
A Carrera product is built to high technical standards and is to be treated with care. Please ensure that you
observe all the instructions contained in this guide. All components have been subjected to careful inspection
(technical modifications and alterations to the model for the purpose of product improvement are reserved).
Should any faults nevertheless occur, guarantee is assumed within the scope of the following conditions:
The guarantee covers demonstrable material or manufacturing defects that existed at the time that the Carrera
product was purchased. The guarantee period is 24 months beginning with the date of purchase. The guarantee
does not extend to wearing parts (such as Carrera RC rechargeable batteries, antennas, tyres, gearbox compo-
nents etc.), damage caused by improper treatment or use (such as performing jumps in excess of the recommend-
ed height, dropping the product etc.), or unauthorised intervention. Repair may only be performed by Stadlbauer
Marketing + Vertrieb GmbH itself or by a company it has authorised to do so. Within the scope of this guarantee,
either the product as a whole or only the defective components will be replaced or equivalent substitution per-
formed, as deemed appropriate by Stadlbauer Marketing + Vertrieb GmbH. The guarantee does not cover trans-
port, packaging or travel costs or any damage for which the buyer is responsible. These costs are to be covered by
the buyer. Guarantee claims will only be accepted from the original purchaser of the Carrera product.
Guarantee claims can only be accepted when:
• The card has been filled in properly and sent in together with the defective Carrera product and the purchase
receipt/invoice/cash-register receipt.
• No unauthorised alterations have been made by the buyer to the guarantee card.
• The toy has been treated in accordance with the operating instructions and subjected to its intended use.
• The damage/faulty operation is not due to acts of God or normal wear and tear.
Guarantee cards cannot be replaced.
Note for EU countries: Reference is hereby made to the seller's statutory guarantee obligation, to the extent
that this guarantee obligation is not restricted by the product guarantee.
6 7 8
beschrieben, eine Bindung zwischen
Notes for AUSTRALIA: Our goods come with guarantees that cannot be excluded under the ACL. You are
entitled to a replacement or refund for a major failure and for compensation for any other reasonably foresee-
able loss or damage. You are also entitled to have the goods repaired or replaced if goods fail to be of accept-
able quality and the failure does not amount to a major failure.
Declaration of conformity
Stadlbauer Marketing + Vertrieb GmbH hereby declares that this model including the controller conforms with
the fundamental requirements of the following EC directives: EC Directives 2001/95/EC and the other relevant
regulations of Directive 2014/53/EU (RED).
The original declaration of conformity can be requested from carrera-rc.com.
Maximum radio-frequency power transmitted <10 dBm · Frequency range: 2400 – 2483.5 MHz
Warning!
This remote-controlled model is NOT A PLAYTHING and is only suitable for young people over 14 years of age.
This model is not intended for use by children, unless they are supervised by a responsible adult. Inappropriate
use may result in severe injuries and/or damage to property. It has to be operated with care and caution and
requires both mechanical and mental skills. The operating instructions contain notes on safety and technical
regulations as well as information on maintaining and operating the product. It is indispensable to read these
instructions thoroughly before the first usage. Only this helps to avoid accidents with injuries and damage.
This symbol, showing refuse bins with a cross through them, denotes that empty
batteries, rechargeable batteries, button cells, rechargeable battery packs, equip-
ment batteries, disused electrical equipment, etc. should not be disposed of in
domestic refuse, as they are harmful to the environment and health. Please help to
preserve environment and health and talk to your children about the correct dispos-
al of used batteries and disused electrical equipment. Batteries and disused electrical equipment should be
handed in to the usual collection points where they can be properly recycled.
Do not mix dissimilar battery types or employ new and used batteries together. Empty batteries should be
removed from the product. Do not recharge non-recharge able batteries due to risk of explosion.
WARNING!
Rechargeable batteries are only to be charged by adults.
Never leave the battery unattended while it is charging.
Rechargeable batteries should be removed from the product before charging. Supply terminal are not to be short-cir-
cuited. Only use the batteries recommended or equivalent types. Batteries are to be inserted with the correct polar-
ity. Battery chargers used with the toy are to be regularly examined for damage to the cord, plug, enclosure and
other parts, and in the event of such damage, they must not be used until the damage has been repaired.
The model is only to be connected to Class II equipment bearing the following symbol.
FCC statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the us-
er's authority to operate the equipment.
NOTE: This product has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful in-
terference in a residential installation. This product generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If
the product does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures :
• Reorient or relocate the receiving antenna.a
• Increase the separation between the product and receiver.
• Connect the product into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
IC statement
The device contain license-exempt transmitter(s)/ receiver(s) that comply with Innovation, Science and Eco-
nomic Development Canada's licence-exempt RSS(s). Operation is subject to the following two conditions:
1. The device must not cause interference;
2. The device must accept any interference, including interference that may cause undesired operation of the device.

Safety instructions

A Carrera RC vehicle is a remote-controlled model car that uses special rechargeable batteries for this
A
purpose. Only original Carrera RC LiFePO
ies are to be removed from the toy before being charged.
The Carrera RC vehicle is designed for hobby use only and may only be operated on tracks and in spaces
B
especially intended for this purpose. WARNING! Do not use the Carrera RC vehicle in road traffic.
Do not operate the car beneath overhead high-voltage cables or broadcasting masts or during a storm!
C
Atmospheric disturbances can affect the operation of the vehicle. When there a large temperature
differences between your car's garage and the running track, please wait until the vehicle has had time
to acclimatise. This will help prevent conden sation forming and the possibility of malfunctions resulting.
Never operate the product on grass surfaces. There is the risk of grass hindering the movement of the
D
axles, which can lead to the motor overheating. Do not use the Carrera RC vehicle for transporting
goods, persons or animals.
Never use the Carrera RC vehicle outdoors during rain or snowfall. The car must not be run through
E
water, puddles and snow, and must always be kept stored in a dry place. Wet surfaces without puddles
will not affect the car's performance as the electronic equipment is protected against spray.
Never operate the vehicle near rivers, ponds or lakes, to avoid the risk of the Carrera RC car falling into
F
the water. Avoid running on courses which are laid exclusively with sand.
Do not expose the Carrera RC vehicle to direct sunlight. To avoid the electronics in the car overheating,
G
when temperatures are above 35 ° C, regular short pauses in operation are essential.
Never subject the Carrera car to repeated changes of load – that means continuously reversing it.
H
Always place the car on the floor by hand. Never throw the car on the floor from a standing position.
I
Avoid jumping from jumps or ramps higher than 15 cm (0.49 ft.).
K
3
ENGLISH
Exhausted batteries are to be removed from the toy.
recharge able batteries may be used. Rechargeable batter-
