6 Troubleshooting
Code Display text
H00.74 TBufferTankMissing
H00.75 TBufferTankTop Miss
H00.76 TcascadeFlow Open
H00.77 TcascadeFlow Closed
H00.78 TcascadeFlow missing
H02.02 Wait Config Number
H02.03 Conf Error
H02.04 Parameter Error
H02.05 CSU CU mismatch
H02.16 Int CSU Timeout
H02.36 Funct device lost
H02.40 Function unavailable
H02.45 Full Can Conn Matrix
H02.46 Full Can Device Adm
90
Description
Buffer Tank temperature sensor was
expected but not detected
Buffer Tank Top temperature sensor
was expected but not detected
Cascade Flow temperature sensor is
either removed or measures a
temperature below range
Cascade Flow temperature sensor is
either shorted or measures a
temperature above range
Cascade Flow temperature sensor
was expected but not detected
Waiting For Configuration Number
Configuration Error
Parameter Error
CSU does not match CU type
Internal CSU Timeout
Functional device has been
disconnected
Function unavailable
Full Can Connection Matrix
Full Can Device Administration
Solution
Buffer tank temperature sensor not detected:
Buffer tank temperature sensor is not connec­
ted: Connect the sensor
Buffer tank temperature sensor is not connec­
ted correctly: Connect the sensor correctly
Faulty sensor: replace the sensor
Buffer tank top temperature sensor not detected:
Buffer tank top temperature sensor is not con­
nected: Connect the sensor
Buffer tank top temperature sensor is not con­
nected correctly: Connect the sensor correctly
Cascade flow temperature sensor open:
Bad connection: check the wiring and connec­
tors
Incorrectly fitted sensor: check that the sensor
has been correctly fitted
Sensor is not present.
Faulty sensor: replace the sensor
Cascade flow temperature sensor short-circuited:
Bad connection: check the wiring and connec­
tors
Incorrectly fitted sensor: check that the sensor
has been correctly fitted
Faulty sensor: replace the sensor
Cascade flow temperature sensor not detected:
Cascade flow temperature sensor is not con­
nected: Connect the sensor
Cascade flow temperature sensor is not con­
nected correctly: Connect the sensor correctly
Faulty sensor: replace the sensor
Configuration error or unknown configuration
number:
Reset CN1 and CN2
Configuration error or unknown configuration
number:
Reset CN1 and CN2
Factory settings incorrect:
Parameters are not correct:
Restart the boiler
Reset CN1 and CN2
Replace the CU-GH PCB
Configuration error:
Reset CN1 and CN2
Configuration error:
Reset CN1 and CN2
Replace the PCB
Communication error with the SCB PCB:
Bad connection with BUS: check the wiring.
No PCB: reconnect PCB or retrieve from mem­
ory using auto-detect.
Contact your supplier
SCB not found:
Carry out an auto-detect
SCB not found:
Carry out an auto-detect
