ES350 / ES400
10.

Protective cover

Attention: Before any work on the tool, disconnect the plug from the mains!
Operate the power tool only with installed protective cover and auxiliary handle.
The position of the protective cover on the machine can be adjusted according to the application.
To do this, loosen the hexagon socket screw (G) on the clamping flange. Turn the protective cover to the desired
position and retighten the screw (G) firmly.
11.

Changing the cutting discs

Pay attention to the dimensions of the grinding tools. The mounting hole diameter must fit the mounting flange
without play. Do not use reducers or adapters.
Changing the cutting wheel:
For clamping and loosening the cutting tools, lock the grinder spindle with the spindle lock button (D).
Actuate the spindle lock button only when the grinder spindle is at a standstill. Otherwise, the machine may
become damaged.
With this button depressed rotate the wheel until it has profoundly gone deeper.
The flange (F) can be detached using the supplied wrench (H).
Unscrew the flange completely from the spindle.
Now detach the cutting disc from the machine mount a new disc.
Screw the flange (F) onto the spindle and tighten it with the help of the assembly tool (H) whilst actuating the
spindle lock at the same time.
When using diamond cutting discs, pay attention that the direction-of-rotation arrow on the diamond cutting disc
and the direction of rotation of the machine (see direction-of-rotation arrow on the machine head) agree.
In order to check whether the spindle stop is released before you switch on the tool, turn the spindle
slightly. Check grinding tools before using. The grinding tool must be mounted properly and be able to
move freely.
Carry out a test run for at least one minute with no load. Do not use damaged, out-of-centre or vibrating
grinding tools. Damaged grinding tools can burst and cause injuries.
12.

Cutting depth limiting

Cut depth adjustment and limiting is available as optional accessories.
Attention: The Cutting discs, spacer discs and the
flange nut might heat up enormously during operation.
You could burn your hands or get cut or ripped by the
segments.
Therefore, always use protective gloves when changing
the grinding wheel.
Attention: Before any work on the tool, disconnect the
plug from the mains!
